Summary of Contents for PURE Contour 200i Air

  • Page 2 Should you have a problem with your unit please contact your supplier or contact Pure Support at the address shown on the rear of this manual. If you need to return your product please use the original packaging and include all parts and accessories. We reserve the right to refuse incomplete or badly packaged returns.
  • Page 3 Thank you for choosing Contour 200i Air. This manual will get you up and running in no time, and explains how to make the most of your Contour 200i Air. We’re constantly improving and adding new features to our products. To take advantage of any enhancements made since your product was shipped, please visit www.pure.com where you can download the...
  • Page 4 Safety Instructions Read these instructions – All the safety and operating instructions should be read before this product is operated. Keep these instructions – The safety and operating instructions should be retained for future reference. Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.

  • Page 5: Table Of Contents

    17 Listening to a docked iPod/iPhone/iPad Compatibility Docking your device Selecting the dock Controlling your device 18 Using the auxiliary input 18 Using the digital output 19 Using Contour Setup Manager Contour name assignment 24 Help and specifications 25 Pure Warranty Statement for Australia...

  • Page 6: Getting Started

    • As a docking station for an iPod, iPhone or iPad. See page 17. • As a speaker for an audio device connected via the Aux In connector. See page 18. Note: Contour 200i Air will be referred to as Contour throughout the rest of this user guide. Pure Connect app Make the most of Contour’s high quality audio by installing the free Pure Connect...

  • Page 7: Remote Control

    Remote control Pull the plastic tab from the remote control battery compartment and remove the protective film from remote buttons. Standby Press to switch between Sleep, Standby and On. See page 8. Source Press to switch between AirPlay, Dock and Auxiliary input sources.

  • Page 8: Front/Top Panel Controls And Connectors

    Front/top panel controls and connectors Standby Mute Press to switch Volume down between Sleep, Volume up Standby and On. See page 8. Status page 6. Front panel Status LED When Contour is powered, the Status LED is visible through the front speaker mesh.

  • Page 9: Rear Panel Controls And Connectors

    Use as an adapter. digital audio See page 11. for MP3 player alternative to signal. See or similar. See Wi-Fi setup. See page 18. page 18. page 13. *Diagnostics LED for use by Pure technical support.

  • Page 10: Switching Between Sleep, Standby And On

    Switching between Sleep, Standby and On Contour has three power modes, Standby, Sleep and On. In Standby, Contour uses minimal power (Status LED is bright red). In Sleep mode, Contour remains connected to the wireless network and waits for a source to be selected (Status LED is dimmed red).

  • Page 11: Preparing Contour To Connect To A Wireless Network

    Preparing Contour to connect to a wireless network Introduction Contour can be connected to your wireless network using two different methods. We recommend using Wi-Fi Network Login Sharing, which automatically connects Contour to your wireless network using the Wi-Fi settings on your iPod, iPhone or iPad*.
  • Page 12 Connecting Contour to your wireless network using Wi-Fi Network Login Sharing To connect Contour to your wireless network: Dock your unlocked Apple device (iPod touch, iPhone or iPad) and wait a few seconds while your Apple device authenticates. The Status LED will flash blue and the Apple device will start sharing.
  • Page 13 Air ****** wireless network should now be visible. Select this network. No password is required. 4. Once you have connected to the Contour 200i Air ****** wireless network, you can access the Contour Setup Manager on your setup device’s web browser.
  • Page 14 Stage 2: Accessing Contour Setup Manager Once you have established the temporary connection between your setup device and Contour, you can access Contour Setup Manager as follows: 1. On your setup device, start your web browser (e.g. Safari, Google Chrome, Microsoft Internet Explorer, Mozilla Firefox).

  • Page 15: Preparing Contour To Connect To An Ethernet Network

    Preparing Contour to connect to an Ethernet network 1. Connect an Ethernet cable from the Ethernet port on the back of Contour to your router. Typical Ethernet setup 2. Insert the connector of the mains power adapter into the DC In socket on the rear of 18V DC Contour.

  • Page 16: Using Airplay To Play Audio

    Using AirPlay to play audio Selecting AirPlay as a source Press Source on the remote control until the Status LED is white. If the Status LED is steady white AirPlay has been set up successfully (this can take up to one minute).

  • Page 17: Playing Audio From Itunes

    Playing audio from iTunes Once you have successfully added Contour to the same network as your iTunes computer, iPod touch, iPhone or iPad, it should be automatically detected. To select Contour as an AirPlay device in iTunes: 1. Open iTunes. 2.

  • Page 18: Streaming Audio To Multiple Rooms

    Streaming audio to multiple rooms If you have more than one Contour, you can use AirPlay to simultaneously stream the same audio to each Contour. You can set this up by using iTunes on your computer. To enable AirPlay to simultaneously stream the same audio to each Contour, click on the AirPlay icon and select the Multiple Speakers option.

  • Page 19: Listening To A Docked Ipod/Iphone/Ipad

    Compatibility The dock on Contour is compatible with most iPod, iPhone and iPad models. For the latest information, check the compatibility table on our website: www.pure.com/products/ipod-compatibility. Docking your device Dock your device onto the connector. Your device will start charging as soon as it is docked and will continue charging whether Contour is playing, in Standby or in Sleep mode.

  • Page 20: Using The Auxiliary Input

    Using the auxiliary input Connecting an auxiliary device Connect the line out or headphone socket of your auxiliary device to the Aux In socket on your Contour using a suitable cable. Selecting the auxiliary input Press Source until the Status LED is pink. Using the digital output Using an external digital output device You can connect Contour to a digital output device, such as compatible hi-fi...

  • Page 21: Using Contour Setup Manager

    Click the Bonjour option from the ‘Collections’ menu on the left side of the screen. Double click your Contour 200i Air from the menu (underneath the cover flow) to open Contour Setup Manager. See ‘Using Contour Setup Manager’ on page 19 for more information.
  • Page 22 Menu structure The Contour Setup Manager menus are accessed by clicking tabs at the top of the window. If accessing Contour Setup Manager using a PC or Mac four tabs are visible. If accessing Contour Setup Manager using a mobile device (Android phone, iPad, iPod, iPhone), three tabs are visible.

  • Page 23: Contour Name Assignment

    Connection The Connection tab is divided into two main sections, Product Name and Wireless Network Setup. Product Name Wireless Setup Contour name assignment If you prefer, you can change the name that your network, iTunes and Apple device uses for Contour: 1.
  • Page 24 Advanced The Advanced tab is divided into two main sections, Proxy Server settings and IP address settings. Configuring Proxy Server settings If your network uses a proxy server to connect to the internet, tick the Use Proxy Server checkbox and enter your proxy server details. Click Connect at the bottom of the window to save any changes made.
  • Page 25 A firmware update takes between six to eight minutes. If you want to manually carry out a firmware upgrade, click Update. Contact Pure Technical Support at http://support.pure.com for more information Note: Do not power off Contour while a firmware update is taking place.

  • Page 26: Help And Specifications

    See ‘Network setup’ on page 8 for more information. The Status LED is flashing cyan If the Status LED is flashing cyan, Contour has a firmware error. Contact Pure technical support for assistance. The audio and network connection keeps dropping when using Wi-Fi If using an iPhone, iPod touch or iPad, make sure you’re running the latest version of...

  • Page 27: Pure Warranty Statement For Australia

    If you have any questions about your warranty you can call us toll free ..1800 988 268 What’s covered by this warranty? • Pure agrees to refund, repair or replace, at your election, without charge to you, any part found to be defective during the warranty period.
  • Page 28 Pure UK Headquarters Pure Australasia Pty Ltd Imagination Technologies Ltd. PO Box 5049 Home Park Estate Wonga Park Kings Langley Victoria 3115 Herts, WD4 8LZ Australia United Kingdom sales.au@pure.com www.pure.com http://support.pure.com/au http://support.pure.com 104HW...
