8Ω FREQUENCY RESPONSE
SPL (dB)
110
90
70
20
100
Celestion International Ltd, Claydon Business Park, Great Blakenham, Ipswich, IP6 0NL, England
Tel: +44 (0)1473 835300 Fax: +44 (0)1473 835301 info@celestion.com www.celestion.com
1k
FREQUENCY (Hz)
SUPER
65
Another notch up the power scale, the
Super 65 produces warm and resonant
sound, exceptionally suited to the blues.
Nothing sings quite like it!
GENERAL SPECIFICATIONS
Nominal diameter . . . . . . . . . . . . . . . . 12", 305mm
Power rating . . . . . . . . . . . . . . . . . . . . . . . . . . 65W
Nominal impedance . . . . . . . . . . . . . . . . . . . . . 8Ω
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . 97dB
Chassis type . . . . . . . . . . . . . . . . . . . Pressed steel
Voice coil diameter . . . . . . . . . . . . . 1.75", 44.5mm
Voice coil material . . . . . . . . . . . . . . Round copper
Magnet type . . . . . . . . . . . . . . . . . . . . . . . Ceramic
Magnet weight . . . . . . . . . . . . . . . . . . 20oz, 0.57kg
Frequency range . . . . . . . . . . . . . . . . . . 80-5000Hz
Resonance frequency, Fs . . . . . . . . . . . . . . . . 90Hz
DC resistance, Re . . . . . . . . . . . . . . . . . . . . . 6.84Ω
MOUNTING INFORMATION
Diameter . . . . . . . . . . . . . . . . . . . . . 12.2", 309mm
Overall depth . . . . . . . . . . . . . . . . . . . 4.9", 124mm
Magnet structure diameter . . . . . . . . . . 4.5", 114mm
Cut-out diameter . . . . . . . . . . . . . . . 11.1", 283mm
20k
Mounting slot
dimensions . . . . . . . . . . . . . . . . . . 0.31", 7.9mm Ø
Number of mounting slots . . . . . . . . . . . . . . . . . . 4
Mounting slot PCD . . . . . . . . . . . . . . 11.7", 297mm
Unit weight . . . . . . . . . . . . . . . . . . . . . 4.9lb, 2.2kg
