Celestion CLASSIC Series Manual

CLASSIC SERIES
VINTAGE 30
Delivering enormously detailed, complex overtones, with an intricate vintage 3-D
crunch, for players as diverse as Slash, Steve Stevens and Peter Frampton.
GENERAL SPECIFICATIONS
Nominal diameter . . . . .12", 305mm Nominal impedance . . . . . .8 & 16
Power rating . . . . . . . . . . . . . . .60W Sensitivity . . . . . . . . . . . . . . . .100dB
CLASSIC LEAD 80
A strong mid/bass punch for real presence when playing power chords and a
controlled top-end that gives great projection for solos.
GENERAL SPECIFICATIONS
Nominal diameter . . . . .12", 305mm Nominal impedance . . . . . .8 & 16
Power rating . . . . . . . . . . . . . . .80W Sensitivity . . . . . . . . . . . . . . . . .99dB
G12M GREENBACK
Ideal for bringing drive and definition to modern amps, the G12M can be used
singly in low-power combos or in multiples for high-power rock heads.
GENERAL SPECIFICATIONS
Nominal diameter . . . . .12", 305mm Nominal impedance . . . . . .8 & 16
Power rating . . . . . . . . . . . . . . .25W Sensitivity . . . . . . . . . . . . . . . . .98dB
G12H ANNIVERSARY
Provides serious attitude to soft amp tones, easily cutting through loud stage
levels for chord work and imparting a hard edge to single notes.
GENERAL SPECIFICATIONS
Nominal diameter . . . . .12", 305mm Nominal impedance . . . . . .8 & 16
Power rating . . . . . . . . . . . . . . .30W Sensitivity . . . . . . . . . . . . . . . .100dB
G12T-75
Weapon of choice for Yngwie Malmsteen, the G12T-75 is a high powered
rock player's dream with a tight low-end and aggressive mid-range.
GENERAL SPECIFICATIONS
Nominal diameter . . . . .12", 305mm Nominal impedance . . . . . .8 & 16
Power rating . . . . . . . . . . . . . . .75W Sensitivity . . . . . . . . . . . . . . . . .97dB
G12K-100
In 4x12s the G12K-100 delivers sledgehammer lows, as favoured by Slayer's
Kerry King. In boutique combos it delivers low-end warmth and mid-range attack.
GENERAL SPECIFICATIONS
Nominal diameter . . . . .12", 305mm Nominal impedance . . . . . . . . . . .8
Sensitivity . . . . . . . . . . . . . . . . .99dB
Power rating . . . . . . . . . . . . . .100W
G12 CENTURY VINTAGE
The G12 Century Vintage exhibits a clear, powerful mid-range and bright
top-end with superb fast attack and tracking. Ideal for speed pickers.
GENERAL SPECIFICATIONS
Nominal diameter . . . . .12", 305mm Nominal impedance . . . . . .8 & 16
Power rating . . . . . . . . . . . . . . .60W Sensitivity . . . . . . . . . . . . . . . . .98dB
G10 GREENBACK
This speaker adds real class to small combos and when combined in a 4x10 provides
a raunchy full-bodied tone rich in low-end thump.
GENERAL SPECIFICATIONS
Nominal diameter . . . . .10", 254mm Nominal impedance . . . . . .8 & 16
Power rating . . . . . . . . . . . . . . .30W Sensitivity . . . . . . . . . . . . . . . . .95dB
G10N-40
The G10N-40 is characterised by satisfyingly deep lows that are complemented
by sweet and clear upper mids and an articulate, well-defined top end.
GENERAL SPECIFICATIONS
Nominal impedance . . . . . .8 & 16
Nominal diameter . . . . .10", 254mm
Power rating . . . . . . . . . . . . . . .40W Sensitivity . . . . . . . . . . . . . . . . .95dB
G10 VINTAGE
A worthy successor to the Vintage 10, the G10 Vintage is a 10" speaker with bags
of attitude. Perfect for adding extra girth to small valve amplifiers.
GENERAL SPECIFICATIONS
Nominal diameter . . . . .10", 254mm Nominal impedance . . . . . .8 & 16
Sensitivity . . . . . . . . . . . . . . . . .97dB
Power rating . . . . . . . . . . . . . . .60W
www.celestion.com
DISCLAIMER
This "Loading Speakers into Your Guitar Cabinet" feature is a general guide to loading a Celestion speaker into your combo
amplifier or guitar speaker cabinet. Note that all manufacturers products differ slightly and the photographs shown herein
are for illustrative purposes only. Likewise, the descriptive text is included as guideline advice and further operational steps
may be necessary to complete speaker loading for specific combo amplifier or cabinet models.
Appropriate safety precautions should always be taken when following the advice herein. Celestion accepts no responsibility
for any personal injury or damage to equipment arising from attempting a speaker replacement. If you are in doubt about
any aspect of this advice, please consult a professional amplifier dealer or repair shop.
LIT0691/1012
