Bedienungsanleitung
Seilflasche
2 rollig
AL-A 64 kN
Beschreibung:
Die Seilflasche mit
2 Seilrollen dient zum
Verstärken der
Zugkraft.
Sie besteht aus zwei
Kunststoffseilrollen mit
Kugellagerung und
beid-seitigen
Flanschen aus
.
Aluminium
Abmessungen / Kräfte
64 kN
m a x .
Ø 1 1 , 2
2x16 kN
2x16 kN max
Wartung:
Ausser Reinigung bei grosser
Verschmutzung, keine
Wartung notwendig.
HABEGGER Maschinenfabrik AG
09.02.2017 / KM
Mode d'emploi
Poulie
2 galets
Ref-Nr. 01840/2 und 01840/2/K

Description:

La poulie à 2 galets
sert à dévier ou
renvoyer le câble de
traction, ou alors à
multiplier la force de
traction.
Elle est composé de
deux galets en matière
synthétique, deux
roulements à billes
et de deux plaques
latérales en alliages
d'aluminium.
Dimensions / Charge
5 3
m a x . v = 1 0 m / m i n
Entretien:
Simple nettoyage, sinon
pas d'entrentien.
CH-3600 Thun Switzerland
ba\ala 64 2.doc
Operating instruction
Rope Pulley
2 sheaves
Description:
The rope pulley with 2
sheaves is for use as
snatch block.
Plastic sheaves with
ball-bearing with
aluminium alloy side
plates.

Dimensions / capacity

64 kN
4 8 k N
16 32 16 kN
6 4k N

Maintenance:

Apart from cleaning, no
maintenance required
Tel. 033 / 225 44 44
1 / 2
