GREEN LABEL
GREEN LABEL SPEAKERS ARE PRIMED FOR
HIGH-POWER ROCK PERFORMANCES, WHERE A
FULL-BODIED, WARM, DEFINED TONE IS ESSENTIAL.
BL10-100X
BASS GUITAR LOUDSPEAKER
Frequency Response and Impedance Curves
Celestion, Claydon Business Park, Great Blakenham, Ipswich IP6 ONL, UK
+44 (0)1473 835300 sales@celestion.com www.celestion.com
Celestion adopts a progressive policy and reserve the right to alter drive unit specifications and/or appearance without prior notice 08/08
General Parameters
Nominal diameter . . . . . . . . . . . . . . . . . . 254mm/10in
Power Rating (rms) . . . . . . . . . . . . . . . . . . . . . . 100W
Nominal impedance . . . . . . . . . . . . . . . . . . . . . . . . 8Ω
Voice coil diameter . . . . . . . . . . . . . . . . 38.1mm/1.5in
Magnet type . . . . . . . . . . . . . . . . . . . . . . . . . . . . Ferrite
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94dB
Frequency range . . . . . . . . . . . . . . . . . . . . 45-3500Hz
Coil material . . . . . . . . . . . . . . . . . . . . . . . . . . . Copper
Former material . . . . . . . . . . . . . . . . . . . . . . Polyimide
Cone material . . . . . . . . . . . . . . . . Kevlar loaded paper
Surround material . . . . . . . . . . . . . . . . . . Cloth-sealed
Xmax . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5mm/0.14in
Gap depth . . . . . . . . . . . . . . . . . . . . . . . . . 6mm/0.24in
Voice coil winding width . . . . . . . . . . . . 13mm/0.51in
Small Signal Parameters
D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.21m/8.27in
F
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76.7Hz
s
M
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25.51g/0.9oz
md
M
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.64g/0.128oz
air
Q
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.878
ms
Q
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.653
es
Q
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.532
ts
R
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.67Ω
e
V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25.06lt/0.88ft
as
BI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11.98Tm
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.148mm/N
ms
R
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.883kg/s
ms
L
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.73mH
e
Mounting Information
Diameter . . . . . . . . . . . . . . . . . . . . . . . . 256mm/10.1in
Overall depth . . . . . . . . . . . . . . . . . . . . . 107mm/4.2in
Cut-out diameter . . . . . . . . . . . . . . . . . . . . 229mm/9in
Mounting slot dimensions . . . 6 x 8mm/0.24 x 0.31in
Number of mounting slots . . . . . . . . . . . . . . . . . . . . 4
Mounting slot PCD . . . . . . . . . . . . . . . . . 245mm/9.6in
Unit weight. . . . . . . . . . . . . . . . . . . . . . . . . 2.4kg/5.3lb
Unit conditioned prior to measurement.
