- Page 1 MODEL NO. SCR1808-EO-PL CLOCK RADIO WITH USB CHARGING INSTRUCTION MANUAL PLEASE READ BEFORE OPERATING THIS EQUIPMENT Sylvania Inc. used under license. SYLVANIA is a registered trademark of OSRAM.
- Page 2 Important Safety Instructions Read these instructions. Warning: Changes or modifications to this unit not Keep these instructions. expressly approved by the party responsible for Heed all warnings. compliance could void the user’s authority to operate Follow all instructions. the equipment. Do not use this apparatus near water.
- Page 3 LOCATION OF CONTROLS AL.OFF/ AUTO SCAN D C IN 5 V U S B C H A R G E R F M A N T . 15 16 17 10. LED CLOCK & RADIO FREQUENCY 1. POWER, AL OFF & AUTO SCAN BUTTON 2.
- Page 4 POWER SOURCE D C IN U SB C H A R G ER FM A N T. Plug the included AC/DC adapter (Input:100-240V~ 50/60Hz, Output:5V 1000mA) into the POWER JACK on the Clock Radio, and into an AC power outlet to power the unit. BATTERY BACKUP 1.5V “AA”...
- Page 5 PLAYING AM/FM RADIO Auto Tuning the FM Radio 1. Press the POWER/AL.OFF/AUTO SCAN BUTTON to turn the unit on. 2. Press and hold POWER/AL.OFF/AUTO SCAN BUTTON. 3. The unit will scan all local FM radio stations and store in preset memory (Maximum of 20 presets).
- Page 6 Snooze Press the SNOOZE button to delay for an additional 9 minutes. Cancelling the Alarm Press and release the appropriate ALARM button (AL 1 or AL 2) until “OFF” is shown in the display.
- Page 7 USB CHARGE 1. Ensure that the unit is plugged into a wall outlet. 2. Using the appropriate USB charging cable (not included), connect one end to the device and the other to the USB Charging receptacle on the unit. Refer to the user’s manual for your specific device for manufacturers required charging amperage as well as determining the appropriate cable for your device before charging.
Need help?
Do you have a question about the SCR1808-EO-PL and is the answer not in the manual?
Questions and answers
Alarm #2 can’t be un-set. It goes off every day. Help me turn it off please.
To turn off Alarm #2 on the Sylvania SCR1808-EO-PL, press and release the ALARM 2 button (AL 2) repeatedly until "OFF" is shown on the display.
