HEAVY DUTY ELECTRIC FRYERS
Models HDEFS15 HDEFT15
HDEFS15
GENERAL SPECIFICATIONS
HDEFS15: Width: 12" Depth: 24" Height: 16.5"
HDEFT15: Width: 24" Depth: 24" Height: 16.5"
ELECTRICAL SPECIFICATIONS
Model
Volts
HDEFS15
240
HDEFT15
240
HDEFT15
KW
Amps 1 Phase
5.8
23.5
11.5
47.9
Thank you for purchasing this product.
To ensure proper use, we recommend that you
read this instruction manual before operating the
unit.
Type Receptacle Req'd.
1 Phase Only
30A - 240V (NEMA 6-30R)
50A - 240V (NEMA 6-50R)
Operation Manual
NQ20A December 2006
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cecilware HDEFS15
Summary of Contents for Cecilware HDEFS15
- Page 1 HEAVY DUTY ELECTRIC FRYERS Models HDEFS15 HDEFT15 HDEFS15 GENERAL SPECIFICATIONS HDEFS15: Width: 12" Depth: 24" Height: 16.5" HDEFT15: Width: 24" Depth: 24" Height: 16.5" ELECTRICAL SPECIFICATIONS Model Volts HDEFS15 11.5 HDEFT15 Thank you for purchasing this product. To ensure proper use, we recommend that you read this instruction manual before operating the unit.
- Page 2 See Electrical Data table below for the fuse or circuit breaker required for each fryer. ELECTRICAL HOOKUP: Single Fryer HDEFS15 – comes supplied with a 240V Single Phase Grounded line cord (NEMA 6-30P). Dual Fryer HDEFST15 – comes supplied with a 240V Single Phase Grounded line cord (NEMA 6-50P).
-
Page 3: Maintenance
High Limit Control : If, due to a defective thermostat, temperature of fat continues to rise, high limit control** automatically shuts off heating element(s). When this happens, red pilot light** on control panel comes on. If high limit control should activate, turn off thermostat and allow fryer to cool. - Page 4 4. Replacing Thermostat Remove back cover of control panel. On all fryers, thermostat is located in control panel. Disconnect wires and remove mounting screws. On all fryers, remove bulb clamps from heating element and pull bulb through rubber grommet in control panel.
- Page 6 Porcelain Connector (Terminal Block) 02311 Left Basket 02312 Right Basket 02313 Tank 02314 4” Adjustable Leg (set of 4) 02303 Handle Power Cord 240V 30Amp CG99A CH402 Power Cord 240V 50Amp Contactor ** SPARE PARTS LIST ** Description HDEFT15 HDEFS15 (Single) (Twin)
-
Page 7: Wiring Diagrams
HEAVY DUTY ELECTRIC FRYER Model: HDEFS15 240 VOLTS - 60 Hz. - 1 PH. - 5.75 kW. L1, L2, + GND EH1 - HEATING ELEMENT K1 - SWITCHES KM1- CONTACTOR HL1 - POWER LED HL2 - HEATER LED ST1 - HI-LIMIT...
