ICED TEA MODULAR BREWER
Brewer
Dispenser only
Dispenser w/Round Stand
Capacity
Cecilware sells value... Worldwide
43-05 20th Avenue, Long Island City, NY 11105
FTC 3, 5, 10 GALLON
MODEL NUMBERS:
FTC-3
FTC-3.5
S3C
S3.5C
SU-3P
SU-3P
3 Gallon
3.5 Gallon
• 718-932-1414
FAX. 718-932-7860
1
DISPENSER SYSTEM
AND
CONTENTS:
• Specification
• Installation & Start-Up
• Tea Strength Adjustment
• Cleaning and Sanitizing
• Trouble Shooting Guide
• Wiring Diagram
• Brew Volume
• Parts List
FTC-5
S5C
SU-5P
5 Gallon
Adjustment Diagram
FTC-10
S10C
SU-10P
10 Gallon
N866A 3/29/99
Advertisement
Table of Contents
Related Manuals for Cecilware FTC-10
Summary of Contents for Cecilware FTC-10
- Page 1 ICED TEA MODULAR BREWER Brewer Dispenser only Dispenser w/Round Stand Capacity Cecilware sells value... Worldwide 43-05 20th Avenue, Long Island City, NY 11105 FTC 3, 5, 10 GALLON MODEL NUMBERS: FTC-3 FTC-3.5 S3.5C SU-3P SU-3P 3 Gallon 3.5 Gallon • 718-932-1414 FAX.
- Page 2 WITH ROUND STAND FTC-5 5 GAL. TEA BREWER 5 GAL TEA DISPENSER 5 GAL TEA DISPENSER– WIDE SU-5P 5 GAL TEA DISPENSER WITH ROUND STAND FTC-10 10 GAL TEA BREWER S10C 10 GAL TEA DISPENSER MODEL NO. FTC-3 FTC-5/10 FTC-3...
- Page 3 2. An approved back flow prevention device, such as a double check valve to be installed between the machine and the wa- ter supply. The FTC-3, FTC-5, FTC-10 are equipped with 1/4 flare water inlet fitting, located in the back of the unit. Connect the ¼" dia. Copper waterline to the ¼" flare water inlet fitting of the valve.
- Page 4 Switch must remain in the OFF position until the PRIMING OPERATION has been completed. This procedure protects the Ele- ment from accidental burnout. LOCATION OF TOGGLE HEATER SWITCH: FTC-3, FTC-5, AND FTC-5L, FTC-10; SEE BACK OF TOP CONTROL BOX. PRIMING PROCEDURE: • Turn on the water supply and check for leaks at connections.
-
Page 5: Brewing Instructions
MODEL # FTC-3 FTC-5 FTC-10 Allow approximately 10 minutes for a complete brew cycle. DO NOT remove brew funnel until it has stopped dripping. Serve Fresh Brewed Tea from dispensing faucet into tea glass over ice. ADJUSTMENTS TO BE PERFORMED BY QUALIFIED SERVICE PERSONNEL ONLY. - Page 6 DETAIL A & B FIG. DESCRIPTION 1 3/8 O.D. x 21 1/2 L. 77279 2 3/8 O.D. x 7” 3 3/8 O.D. x 9 1/4 L. 77246 4 3/8 O.D. x 4 1/2 L. 77277 5 3/8 O.D. x 10 1/2 L. 77243 6 3/8 O.D.
- Page 7 FTC-3/5 FUNNEL ASS'Y #V236A RESTRICTOR #K604A [orifice Ø .086] WHITE FUNNEL #V211A TEA LABEL MODEL NO. LABEL CAUTION LABEL #N816A FTC-10 FUNNEL ASS'Y #Q183Q GROMMET M461A [.446 ID] TEA SHELF- RW98A SIPHONING TUBE #K626A [orifice Ø .187] FUNNEL # Q183A DETAIL B...
-
Page 8: Thermostat Adjustment
THERMOSTAT ADJUSTMENT Two types of Thermostats are used on FTC Brewers: Type A - Surface mounted thermostat with slotted adjustment stem. Should not be adjusted past 195º F. Type B - Capillary bulb thermostat with adjustment knob. Should not be adjusted past 203º F. If field adjustments are needed, INCREASE or DECREASE temperature by GRADUALLY rotating the adjustment stem or knob CLOCKWISE OR COUNTER-CLOCKWISE. -
Page 9: Cleaning And Sanitizing Instructions
CLEANING AND SANITIZING INSTRUCTIONS A. MACHINE: Wipe exterior of dMachine with a soft damp cloth. B. DISPENSER [ICED TEA CONTAINER]: PROPER CLEANING AND SANITIZING OF THE FAUCET ON YOUR TEA DISPENSER IS NECESSARY TO DELIVER GREAT TAST- ING FRESH BREWED ICED TEA. TOMLINSON SPB/SPBH FAUCET DO NOT REQUIRE TOOLS FOR CLEANING AND SANITIZING. TO PREVENT BACTERIAL GROWTH FOLLOW STEP BY STEP SEQUENCE AND REFER TO THE DIAGRAM BELOW. -
Page 10: Cleaning Instructions
The Pinch Tube Faucet is used with a super-sanitary, disposable bag and tube. The tube is inserted through the fau- cet; product does not contact the valve. The pinch tube requires not cleaning. Faucet Assembly Instructions: 1. Assemble faucet body [1] to existing shank [2] 2. - Page 11 TROUBLE SHOOTING GUIDE FOR FTC BREWERS PROBLEM NO WATER WHEN BREW A) DISPENSER UNPLUGGED SWITCH IS ACTIVATED B) CIRCUIT BREAKER OFF OR TRIPPED C) POWER SWITCH OFF D) INOPERATIVE DISPENSE SWITCH E) INOPERATIVE TIMER F) HOT WATER TANK G) WATER SUPPLY OFF H) INLET SCREEN PLUGGED I) INOPERATIVE INLET WATER VALVE J) LOOSE ELECTRICAL CONNECTION...
- Page 13 REPLACEMENT PARTS LIST FOR TEA BREWER FTC-3, FTC-5, FTC-5L, FTC-10 ITEM DESCRIPTION TOP COVER HOSE .312 ID. 7.25” LONG FLOW CONTROLLER, HOT SIDE, BLACK [orifice Ø.078] SPRAY HEAD FITTING WASHER FLAT 9/16 ID SILICON WASHER 9/16 ID TIMER 120V [“TEACH ME” TIMER–FTC-10] THERMOSTAT [WAS 59016–...
-
Page 15: Tank Assembly
Q172A Q180A M632A M632A DO77A DO77A D076A D076A K524A K524A MO80A MO80A K110A K110A RI65A RW24A FTC-5 FTC-10 97131 97131 06121 06121 K538A K538A 4 / 5 P493A P493A M641A M641A 4 / 5 97214 U781A 97215 97215 20039 20039...
