Pyle PPHP266B User Manual page 4

•
USB Flash Memory Reader
•
Micro SD Memory Card Reader
•
(2) 1/4'' -inch (6.5mm) Microphone/ Guitar Instrument Inputs
•
Master Volume, Mic Volume, Treble, Bass Adjustable
•
Battery Level Indicator Light
•
Convenient Integrated Carry Handle
•
Rugged & Durable Molded Cabinet Design
•
Used for Public Gatherings, Crowd Control, Home Karaoke
•
For Indoor / Outdoor Use
Wireless BT Streaming:
•
Built-in BT for Wireless Music Streaming
•
Simple & Hassle-Free Pairing
•
Works with All of Today's Latest Devices
•
Smartphones, Tablets, Laptops, Computers, etc.
•
Wireless BT Version: 5.0
•
Wireless BT Network Name: 'PYLEUSA'
•
Wireless Range: Up to 32' ft.
Audio Recording Mode:
•
It's Easy: One Button Record Activation
•
Record Audio as Streamed through the Speaker System
•
Ability to Record Vocals via Microphone
•
Recording Files save via USB Flash & Micro SD Ports
•
Can Also Record FM & Wireless BT Streaming Audio
•
Audio File Type Created: MP3
What's in the Box:
•
PA Speaker System
•
Wired Microphone
•
Remote Control
•
Power Adapter
6
www.PyleUSA.com
Technical Specs:
•
Speaker Style: Molded PA Speaker Cabinet
•
Wired Mic Cable Length: 9.8' ft.
•
Impedance: 3 Ohm
•
Frequency Response: 55-20kHz
•
S/N Ratio: 60dB +/-3dB
•
SPL: 94dB (1W/M)
•
T.H.D.: <1%
•
USB Interface Type: 2.0
•
Digital Audio File Support: MP3
•
Maximum USB/Micro SD Flash Support: Up to 32GB
•
Mic Nominal Current Drain: <100mAh
•
LED Light Power Control Switch: ON / OFF
•
Construction Material: Engineered Polypropylene (PP)
•
Battery Life: Up to 2 Hours (Charge Time Approx. 4Hours)
•
PA Speaker Rechargeable Battery: 7.4V Li-ion, 1800mAh - 13.3Wh, 120g
•
Battery Operated Remote: (1) x CR-2025 Button Cell, Included
•
Power Cable Length: 3.6' f.t
•
Power Supply: 120/240V (9V Power Adapter)
This product can expose you to a chemical or group of checmicals, which may include
"Lead and lead compounds" which is known in the state of California to cause cancer, birth
defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
Questions? Issues?
We are here to help!
Phone: (1) 718-535-1800
Email: support@pyleusa.com
