B E A S L E Y
THERMOSTATIC SHOWER VALVE
VÁLVULA DE DUCHA TERMOSTÁTICA BEASLEY
SKU: 948778
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing �xtures. Signature
Hardware accepts no liability for any damage to the
plumbing, wall, or for personal injury during
installation.
Observe all local plumbing and building codes.
Unpack and inspect the product for shipping
damage. If any damage is found, contact our
Customer Relations team at 1-800-221-3379.
ANTES DE COMENZAR
Le recomendamos que consulte a un profesional si no
sabe cómo instalar accesorios de plomería. Signature
Hardware no asume ninguna responsabilidad con
respecto a los daños causados a la plomería, la pared, ni
por daños personales que ocurran durante la
instalación.
Cumpla con todas las normas locales de plomería y
construcción.
Retire el producto del empaque y verifique si no sufrió
daños durante el envío. Si encuentra algún daño,
comuníquese con nuestro equipo de Servicio al cliente
al 1-800-221-3379.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
CÓMO COMENZAR
Asegúrese de haber reunido todos los materiales
necesarios para la instalación.
TOOLS AND MATERIALS:
HERRAMIENTAS Y MATERIALES:
Plumbers Tape
Cinta Selladora
Para Rosca
Safety Glasses
Long-nose Pliers
Pinzas de punta
Gafas de seguridad
Adjustable Wrench
Llave Ajustable
1
Pliers
Hex Wrench
Llave hexagonal
Pinzas
de punta
Phillips
Screwdriver
Destornillador
Phillips
REVISED 02/24/2020
CODES: SHBE9009, SH6004, SH6006
1.800.221.3379
