V I L A M O N T E
WIDESPREAD BATHROOM FAUCET
GRIFO DE BAÑO EXTENDIDO VILAMONTE
SKU: 948600
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing fixtures. Signature
Hardware accepts no liability for any damage to the
faucet, plumbing, sink, countertop, or for personal
injury during installation.
Observe all local plumbing and building codes.
Unpack and inspect the faucet for shipping damage.
If any damage is found, contact our Customer
Relations team at 1-800-221-3379.
ANTES DE COMENZAR
Le recomendamos que consulte a un profesional si no
sabe cómo instalar accesorios de plomería. Signature
Hardware no asume ninguna responsabilidad con
respecto a los daños causados al inodoro, sistema de
plomería, suelo o daños personales durante
la instalación.
Cumpla con todas las normas locales de plomería y
construcción.
Retire el inodoro del empaque y verifique si se
produjeron daños durante el envío. Si encuentra algún
daño, comuníquese con nuestro equipo de Servicio al
cliente al 1-800-221-3379.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
CÓMO COMENZAR
Asegúrese de haber reunido todos los materiales
necesarios para la instalación.
TOOLS AND MATERIALS:
HERRAMIENTAS Y MATERIALES:
Basin Wrench
Adjustable Wrench
Llave de grifo
Llave Ajustable
Safety Glasses
Gafas de seguridad
suministro flexible
1
Plumbers Tape
Cinta Selladora
Para Rosca
2 Flexible
Silicone Sealant
Supply Line
(100% Neutral Cure)
2 Línea de
Sellador de silicona
(100% curado neutro)
REVISED 9/30/2019
CODES: SHWSCVL800
1.800.221.3379
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Signature Hardware Vilamonte 948600
Summary of Contents for Signature Hardware Vilamonte 948600
- Page 1 V I L A M O N T E WIDESPREAD BATHROOM FAUCET GRIFO DE BAÑO EXTENDIDO VILAMONTE SKU: 948600 BEFORE YOU BEGIN TOOLS AND MATERIALS: HERRAMIENTAS Y MATERIALES: We recommend consulting a professional if you are unfamiliar with installing plumbing fixtures. Signature Hardware accepts no liability for any damage to the faucet, plumbing, sink, countertop, or for personal injury during installation.
-
Page 2: Installation
V I L A M O N T E WIDESPREAD BATHROOM FAUCET GRIFO DE BAÑO EXTENDIDO VILAMONTE SKU: 948600 INSTALLATION 3. Before installation of hot and cold end valves, if the handle seat is not aligned with handle in a line as INSTALACIÓN shown in the above diagram (1), rotate the handle seat back (the rotating angle can not exceed 90°) to make... - Page 3 V I L A M O N T E WIDESPREAD BATHROOM FAUCET GRIFO DE BAÑO EXTENDIDO VILAMONTE SKU: 948600 4. Secure end valves with washers and nuts. Hand 6. Make connections to water lines. Use 1/2" IPS tighten nuts onto shank. Lock nuts into position by faucet connections (2) or use supply line coupling nuts tightening screws.
- Page 4 V I L A M O N T E WIDESPREAD BATHROOM FAUCET GRIFO DE BAÑO EXTENDIDO VILAMONTE SKU: 948600 9. Install horizontal rod (2) and stopper (3) as 8. Apply silicone sealant to underside of flange (2). non-removable (4). Hand tighten pivot nut (1). Insert body (1) into drain hole from below sink.
- Page 5 V I L A M O N T E WIDESPREAD BATHROOM FAUCET GRIFO DE BAÑO EXTENDIDO VILAMONTE SKU: 948600 11. After installation is complete, loosen set screw (1) 12. Due to copper tube design, the aeration/filtration with Allen wrench (Hex:1.5mm) (2), then remove has been added to the supply lines.
- Page 6 V I L A M O N T E WIDESPREAD BATHROOM FAUCET GRIFO DE BAÑO EXTENDIDO VILAMONTE SKU: 948600 13. If faucet leaks from spout, shut off the water supplies and replace the cartridge (1). Note: Install cartridge (1) correctly for proper handle rotation.
