Item: SD-AZ054-01**
ANZZI TUB DOOR
INSTALL & OPERATION MANUAL
V1.0
DON'T WAIT!
REGISTER NOW!
Register your product within 90 days to ensure your product is
recognized as an official purchase and is eligible for warranty
coverage.
Mail in the completed registry card (Pg. 2) or register online
at
www.swcorp.com/register
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Anzzi SD-AZ054-01 Series
Summary of Contents for Anzzi SD-AZ054-01 Series
- Page 1 Item: SD-AZ054-01** ANZZI TUB DOOR INSTALL & OPERATION MANUAL V1.0 DON’T WAIT! REGISTER NOW! Register your product within 90 days to ensure your product is recognized as an official purchase and is eligible for warranty coverage. Mail in the completed registry card (Pg. 2) or register online...
-
Page 2: Product Registration
I have read the Owner’s Manual carefully and understand and agree that any installation, operation or maintenance of the product must be done strictly in accordance with instructions and guidelines contained in the owner’s manual and installation guide. Signature____________________________________________________________Date ______________________________________________ Have questions? Call us at 1-844-44-ANZZI or visit us at www.ANZZI.com... - Page 3 1/4" 1/8"...
-
Page 4: Box Contents
Box Contents: 1xInstallation Instruction. [1] 3xWall Plugs. [2] 3xScrews ST4x35. [3] 3xScrew Cover Caps. [4] 3xScrews ST4x8. [5] 1xWall Post. [6] 1xDeflector. [7] 1xWater Deflector. [8] 1xFixed Panel. [9] 1xAllen Key. [10] 1xHandle Set. [11] 2xHinges. 4xScrews ST4x35 [12] 1xDoor Panel. [13] 4xCorner Board Seat. -
Page 5: Assembly Drawing
Assembly Drawing [13] [14] [15] [10] [12] [11] [1] 3xWall Plugs. [9] 1xAllen Key. [2] 7xScrews ST4x35. [10] 1xHandle Set. [3] 3xScrew Cover Caps. [11] 2xHinges. [4] 3xScrews ST4x8. [12] 1xDoor Panel. [5] 1xWall Post. [13] 4xCorner Board Seat. [6] 1xDeflector. [14] 2xCorner Board. - Page 6 SD-AZ054-01** 48*58" 7" 4" 15.8" 10.8" 21.6" 23.6" 47.8-48"...
-
Page 7: Installation Steps
Installation Steps The profile must be checked with the Step 1 spirit level whilst marking. 1/4" Screw ST4x35 Step 2 [15]... - Page 8 Step 3 Screw ST4x35 [11] [11] Note:Please pay attention to the difference between top and bottom hinges. Step 4 [12] [10]...
- Page 9 Step 5 Take extra care not to drill through 1/8" to exterior side. Screw ST4x8 View from inside Step 6 [14] [13] Screw ST4x35 [15]...
- Page 10 Step 7 The sealant should be applied to the outside edge.
