8
Relay terminal blocks
6
Max 30m cable.
For locks with failsafe (power to lock) function, connect
lock to terminal 5, not 3.
Technical data
Power voltage:
Power consumption:
Relay output:
Temperature Range:
Environment:
Dimension (hxwxd):
Recommended mounting height 1200 – 1400 mm. If
the code lock is to be flush mounted, the flush
mounting unit BB3 should be used.
Power supply
Ensure that the power supply is stable and within the
rated voltage of the unit. Use an uninterrupted power
supply (UPS) to ensure a continuous function of the
unit in the event of power dips on the mains supply.
V42
12-24 V AC/DC.
8 mA quiescent.
Voltage free relay, max.
1A, 28V DC.
Cable < 30m.
-35° to +55°C.
Indoor – or outdoor use
(IP54 design).
140 x 80 x 40 mm.
