AMobile K430 Quick Start Manual

Mobile Computing Device
with Keyboard
Quick Start Guide
Overview
Package Content
• 1 x K430 • 1 x Quick Start Guide
• 1 x Lithium Battery
Front View
Receiver
Scan LED
Charging LED
Proximity
Sensor
Touch
Screen
Scan Key
Cursor Left
Cursor Right
key
Key
Function Key
Capital Letter
Function
Lock Key
key Switch
Input Mode Switch
(F1~F10) (Lowercase /
uppercase /
numeric mode)
Microphone
Power Key
-1-
Overview
Rear View/Side View
Scan Engine
Handstrap
Buckle
Camera &
Flash LED
Speaker
Battery Cover
Lock
NFC
Sensor
Area
Battery
Cover
Handstrap
Buckle
USB Cover
Charging
Contact
-2-
Installation
The K430 comes with a Lithium battery in the packing box. Before
installing the battery, it's suggested that you install the Micro SIM/
microSD card first as described below.
1. Make sure to use the battery provided with the K430.
Using a wrong battery may result in a risk of explosion.
2. Before installing the battery, make sure all the
components are dry. Using wet components may
cause damage not covered by the warranty.
1. Turn off the K430. Move the battery cover lock button to the
unlock position at right.
Scan
Key
2. Gently pry off the battery cover from the grooves on the sides.
-3-
