Summary of Contents for Thule VW T5
- Page 1 Adapter VW T5/T6 TO 4900 Instructions Prod no.: 301772/ 301773/ 301774/ 301775 Bring your life Doc. no.: AD977-00 / 3380050000 thule.com Date: 04/09/2018...
-
Page 2: Front Back
Adapter Roof VW T5/T6 TO 4900 Instructions TX 20 TX 30 Ø3,5mm Prod no.: 301772/ 301773/ 301774/ 301775 Bring your life Doc. no.: ADR977 -02 / 3380050000 thule.com Date: 04/09/2018 Ø9mm DIN 7982 - TX20 Thule Omnistor 4900 Instructions 4,2x25... - Page 3 RIGHT HAND DRIVE (RHD) is MIRROR of LEFT HAND DRIVE (LHD) RHD BACK RHD FRONT LHD BACK LHD FRONT IN THIS MANUAL LEFT HAND DRIVE (LHD) IS SHOWN BY DEFAULT L1H1 LHD Roof awning 2,6 m ID 2 ID 1 3000 L2H1 LHD Roof awning 3,00 m...
- Page 4 RHD IS MIRROR OF LHD 2M60 3 4 0 3M00 AD977-00...
- Page 5 RHD IS MIRROR OF LHD Ø Ø AD977-00...
- Page 6 RHD IS MIRROR OF LHD Ø9mm AD977-00...
- Page 7 Glue / Lijmen / Verklebung / Coller: RHD IS MIRROR OF LHD Thule recommends / beveelt aan / empfehlt / recommande: SIKA 252 or Terostat MS937 Preparation and sealing according to the prescripts of the glue supplier. 48 h Voorbehandeling en afdichting volgens de voorschriften van de lijmfabrikant.
- Page 8 RHD IS MIRROR OF LHD M6 x 16 Adapter Set DIN 7985 TX30 Front & Back TX 30 TO 4900 - 2,60M/3,00M Drill Ø3mm AD977-00...
- Page 9 RHD IS MIRROR OF LHD 4.2 x 16 DIN 7981 TX20 A2 TX 20 AD977-00...
- Page 10 AD977-00...
- Page 11 AD977-00...
- Page 12 Thule NV, Kortrijkstraat 343 – BE 8930 Menen, BELGIUM infoRV thule.com...
