Important!
1. When you receive your Newline shower check contents for any freight damage.
2. Advise Newline on 0508 639 5463 if any damage has occurred or a defect
identified within 8 hours of receiving the goods so this can be rectified.
3. Do not proceed with installation until resolved.
November 2019
Slider
INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the Slider and is the answer not in the manual?

Questions and answers

Related Manuals for NewLine Slider

Summary of Contents for NewLine Slider

  • Page 1 1. When you receive your Newline shower check contents for any freight damage. 2. Advise Newline on 0508 639 5463 if any damage has occurred or a defect identified within 8 hours of receiving the goods so this can be rectified.

  • Page 2: Warranty

    Sika Silaflex NG translucent Silicone TOOLS REQUIRED AFTERCARE Newline recommend squeegeeing down the glass after every shower and cleaned weekly with a microfiber cloth, mild detergent and water. Rinse with clean water and squeegee and wipe dry. NEWLINE RECOMMENDS A SKILLED TRADESMAN ACQUAINTED WITH...

  • Page 3: Preparation Checklist

    DOOR SET / IMPORTANT INFORMATION PREPARATION CHECKLIST ENSURE YOU TICK THE SPECIFIC BOXES THAT APPLY AS YOU PROGRESS 2 Sided Shower: Ensure the floor is level and the walls are plumb and flat. Position all framing for solid fixing for the shower tray, shower and plumbing fittings. Wall profiles require a stud flush with the tray outside edge.
  • Page 4 COMPONENT LIST: 2-SIDED COMPONENT LIST: 2-SIDED DOOR AND RETURN PANEL...

  • Page 5: Layout Options

    SHOWER TYPE WALL CHANNEL ADJUSTMENT 900mm Return Panel 870mm (minimum) to 888mm (maximum) 1200mm Door 1165mm (minimum) to 1185mm (maximum) Walls out of plumb will not allow for full minimum/maximum options. Apply silicone bead down back of channel prior to fastening.
  • Page 6 For details on door set assembly: 1. Door frame: Step 3 this page. Fit return panel. 2. Glass door: Page 7 Step 4 & 5 Top & Bottom Rails (03). Fit with bump stops at fixed glass end. Door Assembly...
  • Page 7 Door parts and seals Plumb corner Connect door set to Adjust shower inwall profiles and post and pack if return panel. Drill and square up door. Drill and fasten required. fasten at corner. door frame to wall profile.
  • Page 8 Apply silicone to join as indicated. Seal the join between wall profile and frame, 150mm up from base on both sides. Finally adjust door alignment.
  • Page 9 COMPONENT LIST: 3-SIDED ALCOVE COMPONENT LIST: DOOR SET 3-SIDED ALCOVE...
  • Page 10 SHOWER TYPE WALL CHANNEL ADJUSTMENT 1200mm 1155mm (minimum) to 1185mm (maximum) Walls out of plumb will not allow for full minimum / maximum options. Top & Bottom Rails (03). Fit with bump stops at fixed glass end. Door Assembly Position wall profiles onto door frame.
  • Page 11 NOTE: Use Pivot Shower (p.10) has details required. Layout Mark wall profile holes both sides. Predrill liner with 2mm bit. Silicone bead on back of wall channels prior to installation. Fasten wall profiles.
  • Page 12 Door Parts Press button Door Installation...
  • Page 13 Seal Install Fitting of seals Adjust rollers to alignment. Adjust rollers but do not Align door frame Fasten frame over tighten. within wall channels to wall profile. and square up door.
  • Page 14 Apply silicone to outer join as indicated. Seal the join between wall profile and frame, 150mm up from base on both sides. CONTACT Freephone: 0508 639 5463 Phone: 09 444 2053 Fax: 09 443 0044 Email: info@newline.co.nz www.newline.co.nz...
