- Page 1 SilkWorm 2000 Entry Family Reference Publication Number 53-0000010-02...
- Page 2 Publication 53-0000010-02 BROCADE, SilkWorm, Fabric OS, QuickLoop, and the BROCADE logo are trademarks or registered trademarks of Brocade Communications Systems, Inc., in the United States and/or in other countries. All other brands, products, or service names are or may be trademarks or service marks of, and are used to identify, products or services of their respective owners.
- Page 3 Canadian Requirements This class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numerique de la classe A respecte toutee les exigences du Regiements sur le material brouilleur du Canada. SilkWorm 2000 Entry Family Reference...
- Page 4 Standards, 21 CFR Subchapter J. Battery Replacement CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. SilkWorm 2000 Entry Family Reference...
-
Page 5: Table Of Contents
Power Supply ......... . . SilkWorm 2000 Entry Family Reference... - Page 6 SilkWorm 2000 Entry Family Reference...
-
Page 7: The Silkworm 2010 Loop Switch
2 microseconds from switch port to switch port. Seven of the eight ports on the SilkWorm 2000 Entry Family switches are fixed short- wave length optical media for interconnecting devices at distances up to 500m. One port is configured as a removable GBIC slot providing the flexibility to configure other physical media such as long-wave length optical or copper. -
Page 8: The Silkworm 2050 Full Fabric Switch
SilkWorm fibre channel switches to build a highly scalable SAN fabric capable of supporting thousands of attached storage devices. The SilkWorm 2050 supports F, FL, and E port connections and Distributed Name Server (DNS). SilkWorm 2000 Entry Family Reference... -
Page 9: Setup And Installation
The SilkWorm 2000 Entry Family switch is ready to go once the unit is plugged in. The SilkWorm 2000 Entry Family switch meets IEC 61000-4-5 surge voltage requirements. -
Page 10: Initialize The Switch
Ethernet cable. Serial Port Connection The SilkWorm 2000 Entry Family has a serial port for initial configuration of the IP address. This port may also be used for service purposes. The serial port should not be used during normal operation. - Page 11 12. Power up the switch. IP based management (telnet, SNMP or WebTools) can now be accessed by using the newly defined IP address. 13. Record the IP address on the label provided on the switch. SilkWorm 2000 Entry Family Reference...
-
Page 12: Status Indicators
AC Module LED Description No light showing No power is being supplied to the switch. Check power cord connection to the switch. Steady Green Receiving power. Switch is online. SilkWorm 2000 Entry Family Reference... -
Page 13: Installation Considerations
Route and support the power cord to ensure that the switch moves freely on its slides without crimping or damaging the power cord or interfering with other equipment and cabling installed in the rack. SilkWorm 2000 Entry Family Reference... - Page 14 Setup and Installation SilkWorm 2000 Entry Family Reference...
-
Page 15: Diagnostics
Run offline. Control Message Inter- cmiTest Verifies that control messages can be face (CMI) Conn Test sent from ASIC to ASIC. Run offline. Content Addressable camTest Verifies CAM functionality. Memory (CAM) Test Run offline. SilkWorm 2000 Entry Family Reference... -
Page 16: Error Messages
To analyze error messages, access the error message log via a telnet session and the errDump command. Note any messages before removing power from the switch; error messages are stored in RAM and are lost when power is removed. See Fabric OS for a detailed description of each message. SilkWorm 2000 Entry Family Reference... -
Page 17: Specifications
Back-to-front airflow (AC power connection out front) Environmental The acceptable environmental ranges for a SilkWorm 2010/2040/2050 switch are shown in Table A-2: Table A-2 SilkWorm 2010/2040/2050 Environmental Specifications Specification Value °C to 40 °C Temperature (operating) SilkWorm 2000 Entry Family Reference... -
Page 18: Dimensions
Input voltage 85 VAC minimum to 264 VAC maximum Input line frequency 47 Hz minimum to 63 Hz maximum Harmonic distortion Power factor correction per IEC1000-3-2 BTU rating 110 watts x 3.412 BTU/hr/watts = 375 BTU/hr SilkWorm 2000 Entry Family Reference...
