Copyright © 2013 All rights reserved. No part of this material may be reproduced
or transmitted in any form without the express written permission of
Briggs & Stratton Power Products Group, LLC.
MASSEY FERGUSON is a trademark of Briggs & Stratton Power Products Group, LLC
Operator's Manual
2000 Series Riding Mower
Mfg. No.
Description
2690969
2023, Tractor & 42" Mower Deck
2691058-00
2020, Tractor & 42" Mower Deck
2691059-00
2021, Tractor & 42" Mower Deck
2691059-01
2021, Tractor & 42" Mower Deck
1696022
42" Mower Deck
1696213-00
42" Mower Deck
1696198-00
42" Mower Deck
1751962
Revision C
Advertisement
Related Manuals for MASSEY FERGUSON 2000 Series
Summary of Contents for MASSEY FERGUSON 2000 Series
- Page 1 Copyright © 2013 All rights reserved. No part of this material may be reproduced or transmitted in any form without the express written permission of Briggs & Stratton Power Products Group, LLC. 1751962 Revision C MASSEY FERGUSON is a trademark of Briggs & Stratton Power Products Group, LLC...
-
Page 3: Table Of Contents
Warranties ......................26 General Information Thank you for purchasing this quality-built MASSEY FERGUSON riding mower. We’re pleased that you’ve placed your confidence in the MASSEY FERGUSON brand. When operated and maintained according to the instructions in this manual, your MASSEY FERGUSON product will provide many years of dependable service. -
Page 4: Operator Safety
Operator Safety Operating Safety Power equipment is only as safe as the operator. If it is misused, or not properly maintained, it can be dangerous! Remember, you are responsible for your safety and that of those around you. Use common sense, and think through what you are doing. If you are not sure that the task you are about to perform can be safely done with the equipment you have chosen, ask a professional: contact your local authorized dealer. - Page 5 Slope Operation You could be seriously injured or even killed if you use this unit on too steep an incline. Using the unit on a slope that is too steep or where you don’t have adequate traction can cause you to lose control or roll over. A good rule of thumb is to not operate on any slope you cannot back up (in 2-wheel drive mode).
- Page 6 Read these safety rules and follow them closely. Failure to obey these rules could result in loss of control of unit, severe personal injury or death to you, or bystanders, or damage to property or equipment. This mowing deck is capable of amputating hands and feet and throwing objects. The triangle in text signifies important cau- tions or warnings which must be followed.
- Page 7 SLOPE OPERATION WARNING Slopes are a major factor related to loss-of-control and tip-over Never operate on slopes greater than 17.6 percent accidents, which can result in severe injury or death. Operation (10°) which is a rise of 3-1/2 feet (106 cm) vertically in on all slopes requires extra caution.
- Page 8 SERVICE AND MAINTENANCE Safe Handling of Gasoline 1. Extinguish all cigarettes, cigars, pipes, and other 13. If the fuel tank must be drained, it should be drained out- sources of ignition. doors. 2. Use only approved gasoline containers. 14. Replace faulty silencers/mufflers. 3.
- Page 9 Decal Locations Operating Instructions, Part No. 1734879 Ignition Switch Positions Part No. 1722806 Danger, Side Dis- charge Models Danger, Side Dis- Part No. 1704277 charge Models Part No. 1704276 1730264 173xxxx Transmission Release Height of Cut Part No. 1730202 Part No. 1730264...
-
Page 10: Features And Controls
Features and Controls Figure 1 Tractor Controls Throttle/Choke Control Headlights (Choke-A-Matic) The light switch turns the tractor headlights on and off. The throttle/choke controls the engine speed and choke (see Figure 1). Move the throttle/choke to the FAST po- sition to increase engine speed and SLOW position to Reverse Mowing Option (RMO) decrease engine speed. - Page 11 Seat Adjustment Lever PTO Switch The seat can be adjusted forward and back. Move the The PTO (Power Take-Off) switch engages and disen- lever, position the seat as desired, and release the lever gages attachments that use the PTO. To engage the to lock the seat into position.
- Page 12 Cruise Control Operation Parking Brake Function TO ENGAGE: Applying the Parking Brake - To lock the parking brake, release the ground speed pedals (A, Figure 2), fully de- 1. Pull up on the cruise control knob (D, Figure 2). press the brake pedal (B), pull UP on the parking brake 2.
-
Page 13: Operation
Operation Safety Interlock System Tests Adding Fuel This unit is equipped with a Safety Interlock System. Do WARNING not attempt to bypass or tamper with the switches and devices. Fuel and its vapors are extremely flammable and Test 1 — Engine should NOT crank if: explosive. - Page 14 Driving the Tractor WARNING Engines give off carbon monoxide, an odorless, 1. Sit in the seat and adjust the seat so that you can com- colorless, poison gas. fortably reach all the controls and see the dashboard Breathing carbon monoxide can cause nausea, display.
- Page 15 Reverse Mowing Option (RMO WARNING Mowing in reverse can be hazardous to bystanders. Tragic accidents can occur if the operator is not alert to the presence of children. Never activate the RMO if children are present. Children are often attracted to the unit and the mowing activity.
- Page 16 Attaching a Trailer Stopping the Tractor and Engine The maximum horizontal drawbar force allowed is 63 lbs (280 N). The maximum vertical drawbar force is 36 lbs WARNING (160 N). This equates to a 250 lb (113 kg) trailer on a 10 Fuel and its vapors are extremely flammable and degree hill.
-
Page 17: Maintenance
Maintenance Maintenance Chart TRACTOR AND MOWER ENGINE Every 8 Hours or Daily First 5 Hours Check safety interlock system Change engine oil - see engine manual Clean debris off tractor and mower deck Every 8 Hours or Daily Clean debris from engine compartment Check engine oil level - see engine manual Every 25 Hours or Annually * Every 25 Hours or Annually *... - Page 18 Battery Charging Battery Maintenance WARNING WARNING Keep open flames and sparks away from the battery; When removing or installing battery cables, disconnect the gasses coming from it are highly explosive. Ventilate the the negative cable FIRST and reconnect it LAST. If not done in battery well during charging.
- Page 19 Removing the Mower Deck WARNING Engage the parking brake, disengage PTO, stop engine, and remove key before attempting to remove the mower deck. 1. Park the tractor on a hard, level surface such as a concrete floor. Turn off PTO switch and engine, remove the key, and apply the parking brake.
- Page 20 5. Install cotter pin (A, Figure 9) and washer (B) that attach mower support (C) to tractor frame. Repeat for other side. 6. Pull the idler pulley lever (A, Figure 10) to release belt tension. Install belt (B) on the PTO pulley (C). PTO Belt Replacement WARNING To avoid damaging belts, do not pry belts over...
- Page 21 Servicing the Mower Blades WARNING For your personal safety, do not handle the sharp mower blades with bare hands. Careless or improper han- dling of blades may result in serious injury. WARNING For your personal safety, blade mounting capscrews must each be installed with a hex/spline washer and spring washer, then securely tightened.
- Page 22 Storage Engine Oil While the engine is still warm, change the engine oil. See Engine Manual. WARNING Never store the unit (with fuel) in an Before starting the unit after it has been stored: enclosed, poorly ventilated structure. Fuel • Check all fluid levels. Check all maintenance items. vapors can travel to an ignition source (such as a furnace, water heater, etc.) and cause •...
-
Page 23: Troubleshooting
Troubleshooting Troubleshooting the Tractor PROBLEM LOOK FOR REMEDY Brake pedal not Fully depress brake pedal. depressed. PTO (electric clutch) Place in OFF position. switch is in ON position. Cruise control engaged. Move knob to NEUTRAL/OFF position. Out of fuel. If engine is hot, allow it to cool, then refill the fuel tank. Engine flooded. - Page 24 Troubleshooting the Tractor (Continued) PROBLEM LOOK FOR REMEDY Internal brake worn. See authorized dealer. Brake will not hold. Steering linkage is loose. See authorized dealer. Improper tire inflation. See Check Tire Pressure section. Tractor steers hard or handles poorly. Front wheel spindle See authorized dealer.
-
Page 25: Specifications
Specifications ENGINE CHASSIS Fuel Tank Capacity 3.5 Gallons (13,2 L) Briggs & Stratton Front Wheels Tire Size: 15 x 6.0-6 Inflation Pressure: 12-15 psi (0,82-0,96 bar) Model Professional Series Rear Wheels Tire Size: 20 x 10.0-8 Horsepower 20 Gross HP @ 3600 rpm Inflation Pressure: 10-12 psi (0,68-0,82 bar) Displacement 32.95 cu in. -
Page 26: Warranties
ABOUT YOUR WARRANTY We welcome warranty repair and apologize to you for being inconvenienced. Warranty service is available only through Massey Ferguson Authorized Service Dealers. Most warranty repairs are handled routinely, but sometimes requests for warranty service may not be appropriate. This warranty only covers defects in materials or workmanship. - Page 28 Massey Lawn and Garden Equipment P.O. Box 702 Milwaukee, WI 53201-0702 1-800-837-6836 masseylawn.com...
