This document explains about the parameters and setting screens for the ZENOLOGY Pro Model Expansion. The parameter names, the order in which they appear and other information may differ, depending on the product.
Page 3
System System CONDITION KEY MODE Simulates the changes that occur as a unit ages. [SOLO] button PITCH DRIFT Sound is produced monophonically. Adjusts the slight pitch drift that occurs when notes are [POLY] button played on an analog synthesizer. Sound is produced polyphonically. [UNISON] button Sound is produced in unison.
Page 4
[RATE] knob [DELAY TIME] knob (LFO RATE) (FLO DELAY TIME) Specifies the rate of the LFO cycle. Adjusts the time from when the key is pressed until the LFO starts to apply modulation.
Page 5
U SUB [RANGE] knob (OSC RANGE) (SUB LEVEL) Specifies the octave of the oscillator. Adjusts the volume of the sub oscillator. 16’ , 8’ , 4' , 2’ NOISE (NOISE LEVEL) (OSC LFO MOD) Adjusts the volume of the noise. Uses the LFO to vary the pitch (vibrato).
Page 6
[FREQ] knob (HPF STEP) Sets the high-pass filter’s cutoff frequency in four steps. 0, 1, 2, 3...
Page 7
[R] [M] [S] buttons (VINTAGE FLT TYPE) If a vintage type model is selected, these buttons change the type of filter. [R] models a Roland filter, and [M] and [S] model vintage synthesizers made by other companies. [FREQ] knob (CUTOFF) (FLT ENV DEPTH) Specifies the cutoff frequency of the low-pass filter.
Page 8
[LEVEL] knob (AMP LEVEL) Adjusts the volume of the tone. [ENV] [GATE] button (AMP ENV SEL) Specifies whether the volume is controlled by the ENV (ENV) or by the gate signal (GATE).
Page 9
Envelope [A] knob (ENV ATTACK) You can edit the ADSR settings of the envelope. Adjusts the Attack time. [D] knob (ENV DECAY) Adjusts the Decay time. [S] knob (ENV SUSTAIN) Adjusts the Sustain level. [R] knob (ENV RELEASE) Adjusts the Release time.
[MFX] button [MFX TYPE] indication [MFX LEVEL] knob Turns MFX on/off. Shows the currently selected Adjusts the MFX output level. MFX name. MFX parameters The edit screen is different for each MFX type.
Page 11
Controller Controller BEND [PIT] knob MOD [LFO] knob (BEND PITCH) (MODULATION LFO) Specifies the range of pitch change produced by pitch Specifies the amount of LFO applied by modulation. bend. BEND [FILT] knob (BEND FILTER) Specifies the range of filter change produced by pitch bend.
