Outdoor housing
Installation manual
1. Content of delivery ....................................... 2
2. Installation oft the outdoor housing .......... 2
3. Technical data .............................................. 6
TV8493-TV8495

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TV8493 and is the answer not in the manual?

Questions and answers

Related Manuals for Abus TV8493

Summary of Contents for Abus TV8493

  • Page 1 Outdoor housing Installation manual 1. Content of delivery ........2 2. Installation oft the outdoor housing ..2 3. Technical data ..........6 TV8493-TV8495...
  • Page 2 Content of delivery  1 camera wall mount bracket  1 hinge element  1 housing base part  1 housing upper part  1 sunshield  1 installation material  1 installation manual Installation oft the outdoor housing The installation of the housing. The cable length starting from the outside of the wall should be mininimum 1,5 meter.
  • Page 3 2.2. Installation of the hinge element 2.2.1. Please route the cables through the hinge element. 2.2.2. Put the hinge element into the bracket with routed cables and fix the element from downside using the fixing screw. 2.3. Installation of the base part 2.3.1.
  • Page 4 2.4. Connections TV 8493 1: Connection for tamper switch 2: Connection 230VAC supply 3: Connection BNC Video 4: Connection 230VDC camera Note:For video and supply cable please use a combined cable (diameter max. 7 mm, min. 5 mm). Only one round cable should be used for one cable gland.
  • Page 5 2.5. Adjustment of camera position 2.5.1. Please remove the screws from the camera tray on the inside of the base partl. 2.5.2. Put the camera on the camera tray. 2.5.3. Fix the camera on the tray using a screw. 2.5.4. Use the long holes to adjust the camera position.
  • Page 6 Technical data  230 VAC connection  Main fuse: T3.15A  Integrated heating  Protection class IP67 (TV8493, TV8494) Protection class IP54 (TV8495)  Inside routed cables  Operation temperature: -20 to +50°C  Weight: 2,56 kg without bracket 3,39 kg with bracket ...

This manual is also suitable for:

Tv8495
