inforce 6401 Quick Start Manual

PACKAGE CONTENTS
BASE KIT
System On Module
(SOM)
Carrier Board
12V Power Adaptor
Micro USB Cable
Acrylic base
21
22
23
24
25
26
27
28
29
30
31
32
33
34
1
3
4
5
2
Your use of this document is subject to and governed by those terms and conditions in the Inforce
6401 Development Kit from Inforce ® Computing Inc. ("Agreement"). You may use this document, which shall be considered part of the defined term "Documentation" for purposes of the Agreement, solely in support of your permitted use of the Inforce 6401 Development Kit under the Agreement. Distribution of this document
Inforce ® Computing is a trademark of Inforce
Qualcomm and Snapdragon are trademarks of Qualcomm Incorporated, registered in the United States and other countries, used with permission. Qualcomm Snapdragon is a product of Qualcomm Technologies, Inc.
PERIPHERALS
ACC1B30 MIPI Display Adaptor Card Kit
ACC1H10 MIPI-CSI Camera Adaptor Board
20
18
19
17
7
13
6
10
9
12
11
8
® Computing Purchase and Software License Agreement for the APQ8064 based Inforce 6401 Development Kit, which you or the legal entity you represent, as the case may be, accepted and agreed to when purchasing a Inforce
is strictly prohibited without the express written permission of Inforce
® Computing Inc., registered in USA and other countries. Other product and brand names used herein may be trademarks or registered trademarks of their respective owners.
This document contains technical data that may be subject to U.S. and international export, re-export, or transfer ("export") laws. Diversion contrary to U.S. and international law is strictly prohibited.
Inforce 6401™ Development Kit
Quick Start Guide
LOCATIONS – Inforce 6401
12 USB3.0 Connector (2.0 mode)
1 Wi-Fi/BT SMA Connector - MHF4
13 USB2.0 Connector
2 Wi-Fi/BT SMA Connector
3 GPS SMA Connector-MHF4 14 Micro SD Card Slot
4 GPS SMA Connector 15 Boot Selection Switches
5 12V DC Jack
16 Power, Vol -, Vol +
6 Audio combo jack
17 Expansion Connector 1
7 Audio standard selection
18 DSI display Connector
8 Wi-Fi/BT SMA Connector - MHF4
19 Fan Header
9 Wi-Fi/BT SMA Connector
20 Camera 1 Connector
10 HDMI Type A Connector
21 RF Cables
11 RJ45 Ethernet Jack
22 Camera 2 Connector
23 Wi-Fi/BT PCB Antenna - MHF4
16
15
14
®
Computing Inc. and its respective licensors, which they can withhold, condition or delay in its sole discretion.
24 Wi-Fi/BT PCB Antenna
25 GPS On-Board Antenna - MHF4
26 GPS On-Board Antenna
27 Wi-Fi/BT PCB Antenna - MHF4
28 Wi-Fi/BT PCB Antenna
29 MHF4 - UFL converter
30 SOM
31 DB9 RS232 Debug
32 3.3V UART Debug
33 µUSB Connector (2.0 mode)
34 Audio Expansion Header
