SYS644X-XX-P1
User Guide
001703 Rev. A
May 26, 2013
Submit technical questions at:
https://www.inforcecomputing.com/techweb/
Confidential and Proprietary – Inforce Computing Inc.
NO PUBLIC DISCLOSURE PERMITTED: Please report postings of this document on public servers or web sites to:
techsupport@inforcecomputing.com
.
Restricted Distribution: Not to be distributed to anyone who is not an employee of either Inforce Computing or its
subsidiaries without the express approval of Inforce Computing.
Not to be used, copied, reproduced, or modified in whole or in part, nor its contents revealed in any manner to others
without the express written permission of Inforce Computing, Inc.
Inforce Computing is a trademark of Inforce Computing Incorporated, registered in the United States and
other countries. All Inforce Computing Incorporated trademarks are used with permission. Other product
and brand names may be trademarks or registered trademarks of their respective owners.
This technical data may be subject to U.S. and international export, re-export, or transfer ("export") laws. Diversion
contrary to U.S. and international law is strictly prohibited.
Inforce Computing Inc.
48820 Kato Road, # 600B
Fremont, CA 94538
U.S.A.
© 2013 Inforce Computing Inc.

Advertisement

Table of Contents
loading

Related Manuals for inforce SYS644 P1 Series

Summary of Contents for inforce SYS644 P1 Series

  • Page 1 NO PUBLIC DISCLOSURE PERMITTED: Please report postings of this document on public servers or web sites to: techsupport@inforcecomputing.com Restricted Distribution: Not to be distributed to anyone who is not an employee of either Inforce Computing or its subsidiaries without the express approval of Inforce Computing.
  • Page 2 Checked By Project Engineer Sebastian Reviewed By Project Engineer Arun V S Approved By Project Manager Devaraj P S 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 3 License Agreement License Agreement Your use of this document is subject to and governed by those terms and conditions in the Inforce Computing Purchase and Software License Agreement for the APQ8064 based 644x development platform, which you or the legal entity you represent, as the case may be, accepted and agreed to when purchasing a 644x development platform from Inforce Computing Inc.
  • Page 4 Power Connect and Disconnect: The AC power supply cord is the main disconnect device to mains (AC power). The socket outlet shall be installed near the equipment and shall be readily accessible 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 5 Thermal and Mechanical Injury: Some components such as heat sinks, power regulators, and processors may be hot; care should be taken to avoid contact with these components. 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 6 Please recycle this device in a responsible manner. Refer to local environmental regulations for proper recycling; do not dispose of device in unsorted municipal waste. 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 7 This document is intended for technically qualified personnel. It is not intended for general audiences. Intended Use All Inforce boards are evaluated as Information Technology Equipment (I.T.E.) for use in personal computers (PC) for installation in homes, offices, schools, computer rooms, and similar locations. The suitability of this product for other PC or embedded non-PC applications or other environments, such as medical, industrial, alarm systems, test equipment, etc.
  • Page 8 Every effort has been made to ensure the accuracy of the document. If you have any comments, questions, ideas regarding user guide, Contact technical support: techsupport@inforcecomputing.com 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 9 Transport Stream Interface UART Universal Asynchronous Receiver Transmitter User Identity Module Universal Serial Bus Active Noise Cancellation Camera Serial Interface 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION viii Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 10: Table Of Contents

    3.1 OPERATING SYSTEM ........................17 4 APPENDIX A ............................18 4.1 DISPLAY ADAPTER BOARD ......................18 4.2 CAMERA MODULE .......................... 18 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 11 Figure 6: QSeven CPU module Top and Bottom ...............12 Figure 7: Boot selection switch ....................14 Figure 8: Display Adapter board with LCD (3D CAD images) ............18 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 12 Table 5: Rear panel locations ....................11 Table 6: CPU Module location ....................12 Table 7: Boot selection ......................14 Table 8: Antenna cable locations ....................16 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION viii Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 13 CPU board: Serial Number  Mini-ITX form-factor carrier board: Serial Number  Ethernet MAC address  001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 14: Hardware Specification

    Mini-ITX form-factor carrier board to provide a functional development platform for your development. Figure 1: Block Diagram 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 15: System Assembly

    SYS644X-XX-P1 User Guide HARDWARE SPECIFICATION 1.2.1 SYSTEM ASSEMBLY Following image shows the overall system. Figure 2: System Assembly 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 16: System Specification

    PLCC Sensor socket miniPCIe slot PCIe Interfaces Standard x1 PCIe slot Q7 Board – 70x70mm Mechanical dimensions Carrier Board – 170X170mm 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 17: Electrical Characteristics

    Table 2: Push button RefDes Function S504 Power Button S505 Reset S502 ZOOM/VOL + BUTTON S503 ZOOM/VOL - BUTTON SW500 CAMERA BUTTON 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 18: Connectors With Customized Pin Out

    ANC Audio Amphenol 103-C0680-00842 Power Amp Terminal Weidmuller 1824420000 NOTE Refer Technical reference manual for the pin out details 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 19: Board Layout And Subsystems

    36. USB Header (Port6&7) 37. SIM Socket 38. NFC Connector 39. MAC Label 40. Serial Label 41. Micro SD card socket 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 20: Figure 3: Carrier Board Top Side

    SYS644X-XX-P1 User Guide HARDWARE SPECIFICATION Figure 3: Carrier board Top side 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 21 SYS644X-XX-P1 User Guide HARDWARE SPECIFICATION 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 22: Figure 4: Carrier Board Bottom View

    SYS644X-XX-P1 User Guide HARDWARE SPECIFICATION Figure 4: Carrier board bottom view 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 23: Figure 5: Carrier Board Rear Panel

    Speaker Left 5.1 audio Jack + Mic External Antenna HDMI Connector DB9 connector LAN port USB-2 USB-3 5V DC Jack 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 24: Figure 6: Qseven Cpu Module Top And Bottom

    8. QCA6234 (WIFI/BT) 9. UFL: WIFI 10. UFL: GPS 11. PMM8920 12. VPH LED 13. Trickle charging LED 14. Expansion Connector 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 25: System Setup And Usage

    Assemble the system as shown above with required options Install the battery (Optional) Connect the required power supply. Press the reset button (S505) 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 26: Hardware Operation

    Resetting the system Quick press and release of the push button (S505) will reset the systems when system runs 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 27: Led Indications

    Voltage for the LVDS connector can be selected either 12V or 5V by placing the jumper shunt as shown in the table below. Voltage Description P510 (Pin 1-2) P510 (Pin 2-3) 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 28: Antenna Cable Location

    WLAN Antenna0 External Antenna J519 Chip Antenna J507 WLAN/BT Antenna1 External Antenna J520 Chip Antenna J505 External Antenna J518 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 29: Software Specification

    SOFTWARE SPECIFICATION 3 SOFTWARE SPECIFICATION 3.1 OPERATING SYSTEM Operating system used in SYS644x is Android Jelly Bean 4.1.2 Version. 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...

  • Page 30: Display Adapter Board

    4 lane primary camera interface and the other one is a 2 lane secondary (webcam) interface. Both interfaces are 40pin connector. 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
  • Page 31 Magrath Road, Bengaluru - 560 025 Karnataka, India. Phone: +91-80-25566699 For technical assistance refer: http://www.inforcecomputing.com/techweb For technical support contact: techsupport@inforcecomputing.com For sales contact: sales@inforcecomputing.com 001703 Rev. A MAY CONTAIN U.S. AND INTERNATIONAL EXPORT CONTROLLED INFORMATION Confidential and Proprietary – Inforce Computing, Inc. Provided under NDA...
