Aqua Simpool Timer Instruction Manual page 56

Simpool Timer Model
Programmable digital peristaltic pump
No. CODE DESCRIPTION
1 ADSP8000195 SIMPOOL PERISTALTIC NEUTRAL SMOKED FRONT COVER
2 ADSP8000029 KNOB TO SECURE CLEAR TEC COVER
3 ADSP4100207 SKF 618/6 BEARING FOR 100LT PUMP COVER
4 ADSP7000638 SIMPOOL TIMER– AQUA PERISTALSTIC POLYCARBONATE LABEL
5 ADSP6000714 STAINLESS STEEL A2 M 2.9 X 13 SCREW UNI 6954 (slotted pan head)
6 ADSP9600001 SIMPOOL PERISTALTIC FRONT FRAME
7 ADSP6000059 PAPER GASKET FOR SIMPOOL DIGITAL PERISTALTIC
8 ADSP6000990 SIMPOOL SKD TIMER WITH INHIBIT (85-265) Vac
9 ADSP9600002 SIMPOOL PERISTALTIC REAR FRAME
10 ADSP6000948 FEMALE BNC PROTECTION FROM BLACK RUBBER PANEL
11 ADSP6000685 3A 250V ON/OFF/PAUSE FLIP SWITCH
12 ADSP6000686 CLEAR PROTECTIVE COVER FOR ON/OFF SWITCH
13 ADSP6000292 CRIMP. CONN.FEMALE BNC CONNECTOR 02.54 L 160 R/N CABLED (Level Conn.)
ADSP6020051 BIPOLAR CABLE 2 X 0.75 3 METRES - H05VV-F 2X0.75 -
14
ADSP6000419 THREE-POLE CABLE 3X0.75 1.5 METRES WITH SCHUKO PLUG - - H05VV-F 3G0.75 -
15
2-POLE FREE-HANGING CONN. PIEZO. BUZZER ASSEMBLY P2.54 WIRES AWG24
16 ADSP6000627B
L=120
17 ADSP6000424 PG7 PITCH CABLE GLAND - 1900.07 - B
ADSP8000078 RPM 20 MOTOR - 230V - (V6084) - Flow rate 3 l/h
18
ADSP8000041 RPM 9.6 MOTOR - 230V - (V6085) - Flow rate 1.4 l/h
19 ADSP8000009A COMPLETE PER-R 4/6-1 ROLLER-HOLDER
20 ADSP8000028 ROLLER-HOLDER GUIDE PIN
21 ADSP8000109 COMPLETE SANTOPRENE TUBE
ADSP7000722 rev. 1.0
INSTRUCTION AND MAINTENANCE MANUAL
23/02/2017
ENGLISH
QTY
1
1
1
1
4
1
1
1
1
2
1
1
1
1
1
1
3
1
1
1
1
56/64
