Setting Sealing Time - Elma DIGIT ZERO Manual

3.4. Use the vacuum sealer with rolls
This vacuum sealer is equipped with a roll holder (2) compatible with Elma
vacuum sealing rolls of the following sizes: 15 x 600 cm, 20 x 600 cm and 30 x
600 cm. To insert the vacuum sealing roll in its holder, gently pull the top lid up.
Next, insert the roll in the holder, unroll approximately 20 cm of material, lift the
cutter (11), passing the edge of the roll through the opening. Pull out enough roll
until you have the length of the bag you wish to make, close the cutter and slide
the blade from right to left to cut the piece of roll you wish to remove. Next insert
one of the sides of the piece of roll in the vacuum chamber. It must be centered
in the vacuum chamber and properly spread out over the sealing bar. Lower the
lid, press the "Seal" button and the machine will seal the piece of roll along that
edge, thereby creating a bag. From here, follow the instructions in section 3.2
Instructions for vacuum packing with bags.

3.5. Setting sealing time

The Digit Zero vacuum sealer enables sealing time to be set by using the di-
gital display. With the machine at rest press the +/- keys to increase or de-
crease the sealing time. The variation interval is 1 second per pulse.
Sealing time should be adjusted according to bag thickness and the sea-
ling bar temperature. Elma recommends a sealing time of 5 seconds.
04. CLEANING
After using the machine, it is recommended to clean the machine case and the
vacuum chamber with neutral soap in order to guarantee hygiene and proper
maintenance of the vacuum sealer. Similarly, it is important that both the sealing
bar and the sealing gasket (9), as well as the vacuum seals (8), are clean at all
times to ensure the bag is properly sealed. Check periodically that the vacuum
chamber is free of any residues or impurities to avoid blockages in the air va-
cuum process.
