Alpha Climatic Installation & User's Instructions page 6

For Alpha E-Tec / Evoke –
•
Gain access to the boiler terminal block as described in the boiler installation
and service instructions.
•
Pass the wire from the Climatic controller through the cable entry point in the
terminal block cover and connect it to terminals 44 & 41 (wires can be
connected either way round).
•
Secure the wire under the cable clamp
•
Remove link wire from terminals 1 & 2
(DO NOT connect Climatic wires into terminals 1 & 2!)
•
Re-assemble in reverse order.
For Alpha E-Tec / Evoke –
•
Gain access to the boiler terminal block as described in the boiler installation
and service instructions.
•
Plug the connecting wire (supplied with controller) onto the Climatic receiver
PCB terminal marked "OT" only.
•
Use the two screws provided from the fixing posts and fix the receiver PCB into
position (Note: Wiring connector faces inwards)
Hard Wired
RF Wireless
6
