Alpha Climatic Installation & User's Instructions page 5

Re-fit the front control panel, lower the control cover (1) and secure the control panel
using the two 10mm screws provided (3).
Installing the batteries (RF Controller Only)
Using a small screw driver un-clip the bottom of the battery cover (2) and remove.
Insert two Size AA batteries in the position shown in the back of the battery
compartment and refit the battery cover
Note: The RF Climatic controller must not be programmed until the receiver
unit is connected to the boiler and RF communication is established.
4. Connecting the Climatic controller
Controls connections are boiler specific, for further details or boiler models not
shown please refer to boiler installation manual.
DO NOT connect Climatic controller to 230v terminals 1 & 2
within boiler control panel!
5
