Valor Black Beauty Oxysafe Installer's Manual

Radiant / convector gas fire

Advertisement

Quick Links

I
N
S
T
A
L
L
E
R
G
U
I
D
E
M O D E L 4 6 6
R a d i a n t / C o n v e c t o r
G a s F i r e
Black Beauty
Please keep in a safe place for future reference
600A734/02

Advertisement

loading
Need help?

Need help?

Do you have a question about the Black Beauty Oxysafe and is the answer not in the manual?

Questions and answers

Summary of Contents for Valor Black Beauty Oxysafe

  • Page 1 M O D E L 4 6 6 R a d i a n t / C o n v e c t o r G a s F i r e Black Beauty Please keep in a safe place for future reference 600A734/02...
  • Page 2 (GB) and the Republic of Ireland (IE) only. This Installer Guide gives sufficient details to enable the appliance to be installed and maintained. If further information is required, our Valor AdviceLine will be pleased to help. Please telephone 0345 626341 (In UK local call rates apply)
  • Page 3 Page Specification Installation Conditions Unpacking Closure Plate Fitting Flue Pull Check Installing the Fire • Hearth Mounting • Wall Mounting Ignition Spark Check Gas Supply Connection Fitting Coal Operation Check Reference Pressure Check Spillage Check Outer Csae Fitting Final Checks & Owner Instruction Servicing •...
  • Page 4 SPECIFICATION The overall dimensions are shown in Fig.1 Figure 1 Overall Dimensions Gross Weight: 21.4kg Burner Type: Duplex Gas Consumption Control Setting Gross Heat Input Btu/h 4.48 15,300 5.36 18,300 3.37 11,500 2.17 7,400 1.26 4,300 Injectors:- 2 off: Bray Cat 88 Size 163 Pressure Setting Cold:- 16.9 + 1.0mbar (6.8 + 0.4in.
  • Page 5 INSTALLATION CONDITIONS The installation must be in accordance with these instructions. For the user’ s protection, in the United Kingdom it is the law that all gas appliances are installed by competent persons in accordance with the current edition of the Gas Safety (Installation and Use) Regulations. Failure to install the appliance correctly could lead to prosecution.
  • Page 6 This fire is suitable for use against walls with combustible cladding. Please note, however, that soft wall coverings (e.g. embossed vinyls etc.) are easily affected by heat. They may, therefore, scorch or become discoloured when close to a heating appliance. Please bear this in mind when installing. 2.10 A minimum clearance of 100mm must be maintained from the side panels of the fire on all installations to allow consumer access for removal of the outer case.
  • Page 7 closure plate must be clear and not covered by tape. CHECK FOR FLUE PULL Apply a lighted match or smoke match to the flue spigot opening in the closure plate and observe the smoke. If there is a definite flow into the opening, pre-heat the chimney for a few minutes and re-test for flow. If there is still no definite flow, the chimney may require attention.
  • Page 8 CONNECT TO THE GAS SUPPLY To gain access for gas supply connection, it is necessary to remove the air guide plate located beneath the main burner. Remove the four screws holding it in place (Fig.6). The levelling screws may need to be withdrawn slightly to allow access to the front two screws.
  • Page 9 This monitoring system must not be adjusted, bypassed or put out of operation. This monitoring system, or any of its parts, must only be exchanged using Valor Authorised parts. Turn on the gas supply and check all joints up to the appliance gas tap for gas soundness using a soap solution or 10.1...
  • Page 10 TEST FOR SPILLAGE A spillage test must be made before the installed ire is left with the customer, carry out the test in the following manner before refitting the outer case. Close all doors and windows in the room 12.1 containing the fire.
  • Page 11 SERVICING Turn off the gas and make sure that the appliance is cool before commencing any servicing. Always test for gas soundness after refitting the appliance. We recommend annual servicing including disconnecting the appliance, checking the catchment space behind the closure plate and clearing any debris.
  • Page 12 15.8 To Remove Rear Injector 15.8.1 Remove the outer case as 15.1 above To improve access, remove the electrode - see 15.5 15.8.2 15.8.3 Release the pipe compression fitting to the rear injector. Lock the injector with a second spanner to ensure that it does not move.
  • Page 13 15.12 To Remove the Flue Switch 15.12.1 Remove the outer case front as 15.1 above 15.12.2 To allow access to the flue switch, remove the two screws securing the right side of the rear outer case (See figure 12). 15.12.2 Loosen the thermocouple connection to the interrupter block and detach the flue switch wires (see fig.
  • Page 14 When reconnecting the thermocouple nut to interrupter block, make sure that the flue switch wires are properly located. Initially screw the thermocouple nut until finger tight, then finally tighten a further quarter turn with a spanner.
  • Page 15 SHORT SPARES LIST Key No. Description No. Off Part No. Gas Tap & Piezo Unit 561209 Piezo Unit 521069 Main Burner Unit 590809 Injector 504949 Electrode Unit 509819 Thermocouple 509839 Flame Effect Burner 509859 Restrictor 510759 Inlet Elbow 532519 Window Unit 505029 Control Knob 520089...
  • Page 16 BS EN ISO 9001 quality system accepted by the British Standards Institute. The Highest Standards Valor is a member of the Society of British Gas Industries which works to ensure high standards of safety, quality and performance. Careful Installation Valor is a Corgi registered company.
