- Page 1 RETRO-CAMERA CCD 1,4’’ UNIVERSALE UNIVERSAL REAR-CAMERA CCD 1,4’’ ITALIANO ENGLISH FRANÇAIS DEUTSCH ESPAÑOL ISTRUZIONI DI MONTAGGIO MOUNTING INSTRUCTIONS INSTRUCTIONS DE MONTAGE MONTAGEANLEITUNG INSTRUCCIONES PARA EL MONTAJE VM 287...
- Page 2 SCHEMA DI COLLEGAMENTO • CONNECTION SCHEME • DIAGRAMME DE CONNEXION ANSCHLUß-DIAGRAMM • ESQUEMA DE CONEXION • NON MODIFICARE PER NESSUN MOTIVO IL CAVO DELLA TELECAMERA. • BY NO MEANS, NEVER MODIFY THE CABLE OF THE REAR-CAMERA. • NE MODIFIER EN AUCUN CAS LE CÂBLE DE LA CAMÉRA DE RECUL. •...
- Page 3 • Per l’utilizzo prolungato (superiore a 5 minuti) collegare in serie al positivo di alimentazione l’integrato 7812. GB • For longer operation-times (more than 5 minutes), connect the IC 7812 in series to the current-supply positive. + 12 V FR • Pour l’utilisation prolongé (supérieur à 5 minutes), brancher en série au positif de l’alimentation l’intégré...
- Page 4 Ø 19 mm. - L. 23 mm. Alimentazione / Power supply Alimentation / Stromzufuhr / Alimentacion Phonocar S.p.A. - Via F.lli Cervi, 167/C - 42124 Reggio Emilia (Italy) Tel. ++39 0522 941621 - Fax ++39 0522 942452 - www.phonocar.com - e-mail:info@phonocar.it...
