Top controls

A Infrared control emitter.
B Directional infrared control emitter. This
emitter rotates 350 (see
Figure 4). Place your Model 88 radio in
its best sounding location. Test the
operation of the radio controls of the
Control Clock 88. Adjust the emitter if
needed.
C " " or " " - alarm one or two time set
controls.
T
C
A
T
C
R
ALARM
R
ONE
ON OFF
F
S N O O Z E
N
CONTROL CLOCK 88
T Turns on tone for alarm one or two.
R Turns on Model 88 radio for alarm one
or two.
F Turns alarm one or two "on" or "off" .
G "SET" - activates time set.
H " " or " " - set desired time.
B T H
T ON
R OFF
ALARM
TIME
RADIO
TWO
ON OFF SET VOL
SLP AM FM
DLY PRESET
M G
Figure 3
Radio controls
I "ON"
J "OFF"
K " VOL " - press left side of button to
raise volume. Press right side to lower
volume.
L "AM FM PRESET" - press left side of
button to cycle through AM preset
stations. Press right side of button to
cycle through FM preset stations.
M "SLP DLY" - Press and hold to activate
sleep delay turn-off period for Model 88
radio (in 10 minute increments up to 60
minutes). Display will show "d10" up to
"d60" , depending on length of time
button is held.
I
N "SNOOZE" - pressing once will defeat
tone or radio sound for a nine minute
J
period. This is repeatable until the alarm
is shut off.
K
Adjust for best radio control
(see Placement)
L
Figure 4
