Front Display; Clock Display - Cambridge SoundWorks Control Clock 88 User Manual

Front display

"ALM ONE" Indicates alarm 1 is on.
"TONE RADIO" Indicates which wake-up will activate; tone, radio or
both.
"ALM TWO" Indicates alarm 2 is on.

CLOCK DISPLAY

Shows the current time. When either alarm's "on"
button (see Figure 3, F) is pressed, it shows the
alarm time, which remains displayed for about 5
seconds after release of the button.
"BATT" Indicates battery needs replacing. After replacement,
this display may take up to 15 minutes to disappear.
This is normal.
To set clock
Hold down "SET" (G) button to activate time setting. Use the "TIME"
buttons, " " or " " (H), to change the current time setting. When setting
time, the display moves forward or back slowly for the first 5 digits, then
proceeds rapidly. If you pass the desired setting, simply reverse direction
to set desired time. The " " and " " buttons are not active unless "SET"
(G) is held down.
Figure 2
Wakeup Operation
• The Control Clock 88 stores two separate wake up times (ALARM ONE
and ALARM TWO).
• Each Control Clock 88 alarm can activate the clock's internal alarm
(TONE), turn on the Model 88 (RADIO), or both. These instructions
apply to either alarm.
• To wake to the radio, be sure the Model 88 is off, and was last tuned to
a radio station and left at an adequate volume.
• The wake up time for either ALARM ONE or ALARM TWO can be
adjusted to an earlier or later time by pressing the " " and " "
buttons (C). This adjustment can be made at any time.
Activating ALARM ONE or ALARM TWO
to "Wake To Radio" and "Wake To Tone"
Press the "ON" button (F). The "TONE" and "RADIO" displays begin
blinking. While the display blinks, select either "T" (tone), "R" (radio), or
both. Pressing either "T" or "R" again will turn off that choice. "ALM
ONE," "ALM TWO," "TONE," or "RADIO" will illuminate on the display. The
Control Clock 88 is now set to wake you as desired.
The display will revert to the current time approximately 5 seconds after
the last button is pressed. To check either alarm's "Wake To" time, press
the "On" button (F). The time will be displayed for 5 seconds.
Turning off the alarms
After the "Wake To Radio" feature has turned on the Model 88 radio, you
may turn off the radio with the "OFF" button (J). The radio may also be
turned off with its faceplate "OFF" button or remote control's power
Low
button "•". Control Clock 88's "Wake To Radio" feature remains active
Battery
Indicator and will turn on the radio 24 hours later.
After the Control Clock 88 wakes you by sounding its internal TONE alarm,
defeat the tone by pressing the "OFF" button (F) on the Control Clock 88.
This "OFF" button (F) may also be used to deactivate either "Wake To
Radio" or "Wake To Tone" settings. "Wake To Radio" or "Wake To Tone"
must be reactivated every time the "OFF" button (F) is pressed.
