- Page 1 640T V2.0 DAB/FM Tuner User’s manual...
- Page 2 Introduction ...3 Safety precautions ...4 Important safety instructions ...5 Rear panel connections...6 Front panel controls ...8 Remote control...10 Operating instructions ...11 Custom installation use...13 Troubleshooting...13 Technical specifications ...14 Limited warranty ...15 2 Azur DAB/FM tuner...
- Page 3 Thank you for purchasing this Cambridge Audio Azur range DAB/FM tuner. These version 2 models are part of our commitment to the on- going development of the Azur range. We hope that you will appreciate the results and enjoy many years of listening pleasure from them.
- Page 4 If the power cord is fitted with a moulded mains plug the unit must not be used if the plastic fuse carrier is not in place. Should you lose the fuse carrier the correct part must be reordered from your Cambridge Audio dealer.
- Page 5 Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
- Page 6 Out - Loop out for control bus commands to another unit. The 640T V2.0 can also output unmodulated codes during alarm/sleep functions to wake and/or put the connected Cambridge Audio amplifier into Standby mode. 6 Azur DAB/FM tuner...
-
Page 7: Connecting The Control Bus
640T V2.0 DAB/FM tuner Connecting the Control Bus If it is desired to control a Cambridge Audio azur amplifier by the tuner’s Alarm or Sleep timers, connect the two units via the orange Control Bus sockets using a RCA/phono lead as shown below:... -
Page 8: Infrared Sensor
5/10 Shift Standby / On Standby/On Switches the unit between Standby and On. When in Standby the front panel display shows the current time in hours and minutes. Presets/Shift The 640T V2.0 can store up to 20 Presets for each of the DAB and FM bands. - Page 9 Strength, Time/Date, NCT mode, Manual Tuning Info, Stereo mode, Bit Rate, Alarm and Sleep. FM mode - Program Type, Radio Text, Signal Strength, Time/Date, NCT mode, Manual Tuning Info, Stereo mode, Alarm and Sleep. Note: The 640T V2.0 has a function which configures the DAB frequency selection and FM de-emphasis to a country’s broadcasting settings.
- Page 10 The 640T V2.0 is supplied with an Azur Navigator remote control that operates both this tuner and Cambridge Audio Azur amplifiers. Insert the supplied AAA batteries to activate. Standby/On Switches the unit between On and Standby mode. The blue LED on the front panel of the unit indicates that it is On when bright and in Standby mode when dim.
-
Page 11: Setting Presets
Tuning and listening 1. Press the DAB/FM button to toggle between DAB and FM modes. When in FM mode, ‘FM’ is shown in the top right hand corner of the display. 2. In DAB mode, press the Skip/Scan buttons to scroll through the receivable stations. -
Page 12: Setting The Alarm
The Alarm function will turn on the 640T V2.0 at a chosen time. It will also generate a command on the Control Bus output that, when connected, will turn on a compatible Cambridge Audio azur series amplifier and cause it to select the tuner input. To set the alarm time: 1. - Page 13 Specific Mute On/Off commands – Press and hold the Mute button. The usual mute toggle command is first, followed by the ‘Mute On’ command, and then the ‘Mute Off’ command. A full code table for this product is available on the Cambridge Audio website at www.cambridge-audio.com. 640T V2.0 DAB/FM tuner There is no power Ensure the AC power cord is connected securely.
- Page 14 This guide is designed to make installing and using this product as easy as possible. Information in this document has been carefully checked for accuracy at the time of printing; however, Cambridge Audio's policy is one of continuous improvement, therefore design and specifications are subject to change without prior notice.
- Page 15 If your dealer is not equipped to perform the repair of your Cambridge Audio product, it can be returned by your dealer to Cambridge Audio or an authorised Cambridge Audio service agent. You will need to ship this product in either its original packaging or packaging affording an equal degree of protection.
- Page 16 www.cambridge-audio.com Part No. AP19189/3...
