CMS-10R FAQ
Storage: https://www.comatreleco.com/betriebsanleitung_cms/

1. FAQ device installation

- Who will install the CMS-10R?
➔ The CMS-10R may only be installed by qualified electricians.
- Why is no LED lit?
➔ Mount the antenna and connect the device with the appropriate rated voltage
(CMS-10R-D: 110 - 240 V AC / CMS-10R-DA and CMS-10R-DAC: 12 - 48V DC).
- What is the status of the LEDs?
➔ Status LEDs Radio signal
These LEDs indicate the currently used radio standard (2G, 3G or 4G).
The colour indicates the signal strength:
➔ Status LEDs Outputs
➔ RUN LED
➔ STAT LED
➔ Status LEDs Inputs
Digital inputs
Analogue inputs
Operating mode
LED not lighting up Fallback: Event storage on the device
LED flashing orange Fallback: SMS directly to recipient
LED lighting up orange Normal operation
LED flashes green Fallback: SMS directly to recipient
LED lights up green Normal operation
Status
LED not lighting up Relay switched off. Relay contact is open
LED lights up Relay switched off. Relay contact is closed
Status
LED not lighting up The device is switched off or is not working, --
see chapter 7.2.
LED flashing The device and the firmware are ready for use and are in operation
Status
LED not lighting up Normal operation
LED flashing Firmware update
LED flashing Firmware update/restart
LED lights up Device shuts down/exits all running tasks
LED flashing Device shuts down/terminates connection to
IoT platform and mobile network
Status
LED not lighting up Input value = logic level 0 (low)
LED lights up Input value = logic level 1 (high)
LED not lighting up Input level ≤ lower threshold value
LED flashing Lower threshold value < input level < upper threshold value
LED lights up Input level ≥ upper threshold value
Radio network IoT-Portal
None not connected
Poor reception not connected
Poor reception Connected
Good reception not connected
Good reception Connected
Flashing frequency
--
--
Flashing frequency
Slow
Flashing frequency
--
Fast, flashing
Slow
--
Fast, even
Flashing frequency
--
--
--
Slow
--
