Nakanishi BMS-4040-RGD-03M Operation Manual

BMS-4040-RGD-03M ・ BMS-4040-RGD-2M
BMS-4040RA-RGD-03M ・ BMS-4040RA-RGD-2M
Thank you for purchasing motor spindle BMS-4040-RGD-03M・BMS-4040-RGD-2M・BMS-4040RA-RGD-03M・
BMS-4040RA-RGD-2M. This motor spindle is designed for high precision machining including grinding, drilling
and milling. The <E4000 CONTROLLER> and the <Air Line Kit> are required to drive this motor spindle. Read
this Operation Manual carefully before use. Also read <E4000 CONTROLLER> and the <Air Line Kit> Operation
Manual.
1 . CAUTIONS FOR HANDLING AND OPERATION
■ Read these warnings and cautions carefully and only use in the manner intended.
■ These warnings and cautions are intended to avoid potential hazards that could result in personal injury or
damage to the device. These are classified as follows in accordance with the seriousness of the risk.
Class
A safety hazard could result in bodily injury or damage to the device if the
WARNING
safety instructions are not properly followed.
A hazard that could result in light or moderate bodily injury or damage to the device
CAUTION
if the safety instructions are not followed.
WARNING
This motor spindle is not a hand tool. It is designed to be used on CNC machines or special
①
purpose machines.
Do not touch the cutting tool while it is running. It is very dangerous.
②
Wear safety glasses, dust mask and hearing protection, and use a protective cover around the
③
motor spindle whenever the motor spindle is rotating.
Never connect, disconnect or touch the Power Cord Plug and Motor Cord Connector with wet
④
hands. This may cause an electric shock.
Never operate or handle the motor spindle until you have thoroughly read the owner's manual
⑤
and safe operation has been confirmed.
1 ) To prevent injuries/damages, check this motor spindle and cutting tool for proper
installation, then operate this motor spindle.
2) Before disconnecting this motor spindle, always turn the control power off and turn the
compressed air supply to the control unit off. It is then safe to remove this motor spindle.
When installing a tool, tighten the collet correctly and check again the collet and collet nut
⑥
before use. Do not over-tighten the collet. This may cause damage to the motor spindle.
Do not use bent, broken, chipped, out of round or sub-standard tools as they can shatter or
⑦
explode. It shatters, it cracked, and the tool that bends and breaks disperses and it causing
injures. When using a new tool, rotate it in a low speed and increase speed gradually for safety.
Do not exceed the maximum recommended allowable tool speed. For your safety, use speeds
⑧
below the maximum allowable speed.
Do not apply excessive force. This may cause tool slippage, tool damage, injury to the
⑨
operator, loss of concentricity and precision.
Motor Spindle
OPERATION MANUAL
Degree of Risk
OM-K0697E 000
1
