Your product
5
15
1. Transportation handle
2. Supply cord
3. On/off switch I/O
4. Water outlet
5. Lower spray gun holder
6. Spray gun
7. Upper spray gun holder
a) Fixing screw
8. Fast pressure hose release button 20. Screw (x8)
9. Wheel (x2)
10. Accessories holder
11. Supply cord storage belt
95815_IM_TTB1800PRW.indd 11
1
2
4
8
3
23
16 17 18
11
10
7
9
1 4 1 2 13
21a
21c
19 20
12. Nozzle holder
13. Water inlet
14. Soap tank
15. Pressure hose
16. Rotary nozzle
17. Vario nozzle
18. Water inlet hose adaptor
19. Cleaning needle
21. Patio brush
22. Extension lance
23. foot
Your product
6
7a
22
21
21b
