- Page 1 VIBRATORY ROLLER Operation and Maintenance Manual 124010 - 73” SMOOTH VIBRATORY ROLLER 124015 - 73” PAD FOOT VIBRATORY ROLLER 124030 - 84” SMOOTH VIBRATORY ROLLER 124035 - 84” PAD FOOT VIBRATORY ROLLER Register your WARRANTY within 30 days of purchase...
-
Page 2: Table Of Contents
ABLE ONTENTS Safety Information ..... . 1 Service....... . 7 Introduction . - Page 3 This Page Intentionally Left Blank...
-
Page 4: Safety Information
Death or serious illness may result if imply or in any way represent that these are the sum of all inhaled. Operate only in an area with proper dangers present near Blue Diamond equipment. If you are ventilation. NEVER... - Page 5 CAUTION Hydraulic Requirements HEAVY PRESSURE: 1500-3000 psi ATTACHMENT (103-207 bar) Overloading skid loader FLOW: 10-50 gpm could cause loader to pitch (38-190 l/m) or tip forward. Return Check lifting capacity of skid loader before hooking onto attachment. Pressure Do not lift attachment over 14435 12”...
-
Page 6: Specifications
PECIFICATIONS 124010 124015 124030 124035 Centrifugal Force 8850 lbs (4014 kg) 9765 lbs (4429 kg) Exciter Speed 3000 rpm 3000 rpm Dynamic Linear Force 121 lb/in (21.7 kg/cm) 116 lb/in (20.8 kg/cm) Amplitude Length 43.3 in (110 cm) 43.3 in (110 cm) -
Page 7: Operation
PERATION Introduction Lower the roller, and engage the loaders’ arms into their float mode. Blue Diamond equipment is intended for use in very severe Engage the auxiliary hydraulics and allow the vibrator applications. to come up to speed. This parts manual contains only standard parts. Variations of these parts as well as other special parts are not included. -
Page 8: Maintenance
AINTENANCE WARNING CAUTION Always exercise the stopping procedure before Always verify fluid levels and check for leaks after servicing or lubricating the unit. changing fluids. After servicing the unit, replace and fasten all Do not drain oil onto ground, into open streams, guards, shields, and covers to their original or down sewage drains. -
Page 9: Checking Exciter Oil
Checking Exciter Oil Rotate drum until check plug is at 6 o’clock position. If oil level is adequate, it should dribble out of hole. Place drum on a level surface If necasary, remove fill/drain plug, and add Blue Remove oil check plug. The plug is the smaller of the Diamond approved Oil. -
Page 10: Service
ERVICE Service Tools Assembly and disassembly should be performed by a service technician who has been factory trained on Blue Diamond equipment. The unit should be clean and free of Part # Description debris. Pressure washing before disassembly 07353 CLUTCH REMOVAL TOOL recommended. -
Page 11: Installing Drive Coupler
To remove coupler gear (# 15) from exciter shaft will Installing Exciter Bearings and Shaft. require 07353 clutch removal tool. Turn coupler gear Refer to Drum Assembly, page 12. clockwise (left hand threads) to remove. Install new bearings (# 8) into housings (# 5 & 14). Installing Drive Coupler Use oil on the OD of the bearing and press on the outer race of the bearing. -
Page 12: Parts Replacement Cycles And Tolerances
Parts Replacement Cycles and Tolerances Replace anytime a bearing is rough, binding, discolored or removed from housing or Bearings shaft. Replace any worn or damaged hardware as needed. Replacement hardware should Hardware be grade 5 and zinc plated unless otherwise specified. Safety Decals Replace if they become damaged or illegible. - Page 13 This page intentionally left blank. - 10 -...
-
Page 14: Replacement Parts
Their sales engineers are available for professional consultation. If you cannot locate an Blue Diamond distributor in your area, contact Blue Diamond or one of our Sales Branches listed below. When ordering replacement parts, be sure to have the STAMP following information available: •... -
Page 15: Drum Assembly
Drum Assembly - 12 -... - Page 16 ITEM PART NO. DESCRIPTION 01072 FILTER, FELT 01191 RETAINING RING, INTERNAL, STAR 07011 RETAINING RING, INTERNAL 08188 DECAL, EXCITER OIL 17807 COVER, EXCITER, BREATHER SIDE 17911 DRUM, ATP73 (PADDED) 17811 DRUM, ATS73 (SMOOTH) 17913 DRUM, ATP84 (PADDED) 17813 DRUM, ATS84 (SMOOTH) 17844 O-RING, 7.234 ID X 0.139 DIA 17845...
-
Page 17: Main Assembly
Main Assembly - 14 -... - Page 18 ITEM PART NO. DESCRIPTION 08213 FITTING, STRAIGHT 08730 FITTING, ELBOW 13166 HOSE, HYDRAULIC 1/2” X 47.00” 17980 HOSE, HYDRAULIC 1/2” X 55.00” 13984 SHEET, SAFETY WALK 24” 14267 MOTOR, HYDRAULIC 14747 FITTING, STRAIGHT 17842 FLAT FACE COUPLING, MALE 1/2” 17843 FLAT FACE COUPLING, FEMALE 1/2”...
-
Page 19: Spider Assembly
Spider Assembly - 16 -... - Page 20 ITEM PART NO. DESCRIPTION SIDE 12475 MOUNT, TORSION 1/2”-13 PRESSNUT 17847 RETAINING RING, EXT 17849 BEARING, BALL 18106 SPIDER, DRUM F071412HCS HEX HEAD CAP SCREW, 7/16”-14 X 1-1/2” F0714ELN LOCKNUT, 7/16”-14 NYLOC - 17 -...
-
Page 21: Warranty
Pallet Forks: may then be returned. Tampering with the failed part may void Blue Diamond Pallet Forks have a one(1) year warranty. If the the warranty. This warranty does not include freight or forks are put in an application where the weight that is lifted delivery charges incurred when returning machinery for exceeds the fork rating, all warranty coverage will be voided.
