COP-USA CM259VAIR-WF Specifications

High Resolution Outdoor IR Bullet Color Camera
CM259VAIR-WF
* 1/3" CCD
* High Resolution 540 TVL
* Built-in 2.5~10mm IR Auto Iris Lens
* 0.001 Lux Slow Shutter (Sense UP 32X)
0Lux with IR on
* DNR (Digital Noise Reduction)
* 36 High Intensity LED's
* IP66 Weather Proof Housing
* DC 12V 800mA
Specification
x
OS
Video
Compression
Video Input
Reset
Network
SD storage
Software
Power
* Specifications are subject to change without notice
IP CAMERA
1/3" High Resolution CCD IR Camera
Processor Hi3512 SoC ARM926 + H.264 Codec
Operating System Linux 2.6.14
Compression H.264 Main Profile@Level 3.0
Full D1 (704x576 * PAL, 704x480 * NTSC)
Half D1 (704x288 * PAL, 704x240 * NTSC)
Video Resolution
CIF
QCIF (176x144 * PAL, 160x112 * NTSC)
Bit Rate 16K ~ 4M bps
25fps at full D1 resolution (PAL)
Image Frame Rate
30fps at full D1 resolution (NTSC)
Composite Input CVBS, 1.0Vp-p with 75Ω loading
Reset Key Factory Default
Ethernet Port Ethernet(10/100 Base-T)
USB 802.11b/g Wireless Network
WiFi
Protocol TCP, UDP, IP, HTTP, DHCP, PPPoE, UPnP etc
SD Card Support SD card local storage Up to 32GB
Web Browser Microsoft Internet Explorer 6.0 or above
Display at most 5X6 pictures at a time/Multiple pages
Client
switching/Timed record
Proxy Timed Record/Trasmit
Remote Player Synchronized multichannel playback. Conjunction with Proxy
SDK ActiveX control, SDK on VC++
Security Password Protection: Configured by the Administrator
Power Requirement DC12V±10%
Power Consumption 1.6W
(352x288 * PAL, 352x240 * NTSC)
** Designed in U.S.A.
