Knurr Elimobil Assembly Instructions

Trolley - base frame

Advertisement

Quick Links

Elimobil – Grundgestell
Elimobil trolley – Base frame
Poste mobile Elimobil – Châssis de base
Assembly Instructions
1
Allgemeine Hinweise
Weitere Dokumentation
beachten
Achtung!
User Manual „Gerätewagen"
unbedingt beachten.
Gültigkeit
Diese Anleitung gilt für folgende Geräte-
wagen-Komponenten der Knürr AG:
Elimobil Grundgestell
Notwendiges Werkzeug
Torx-Schraubendreher T 50
Innensechskantschlüssel 6 mm
und10 mm
2
Montage
Hinweis
Zur Montage der Kufen und Rollen ist es
hilfreich, die Quertraverse kopfüber auf
einen Tisch zu legen.
Kufen an Quertraverse
A
General information
Refer to the other
documentation
Warning!
See user manual entitled "Mobile
workstations".
Validity
These instructions apply to the following
trolley components from Knürr AG:
Elimobil base frame
Tools required
Torx screwdriver T 50
6 mm and 10 mm Allen key
Assembly
Information
It is a good idea to place the crosspiece
upside down on a table to fit the runners
and castors.
Runners on crosspiece
A
A
Technical Furniture
Consignes générales
Respecter les indications
ci-dessous
Attention !
Respecter impérativement le manuel
utilisateur « Postes mobiles ».
Validité
Ce mode d'emploi est valable pour les
éléments de postes mobiles de Knürr AG
suivants :
Châssis de base Elimobil
Outils nécessaires
Tournevis à embout Torx T 50
Clé Allen 6 mm et 10 mm
Montage
Nota
Pour le montage des patins et des roulet-
tes, il est utile de renverser la traverse sur
une table.
Patins de la traverse
4x
6

Advertisement

loading
Need help?

Need help?

Do you have a question about the Elimobil and is the answer not in the manual?

Questions and answers

Summary of Contents for Knurr Elimobil

  • Page 1 ■ Technical Furniture Elimobil – Grundgestell Elimobil trolley – Base frame Poste mobile Elimobil – Châssis de base Assembly Instructions Allgemeine Hinweise General information Consignes générales Weitere Dokumentation Refer to the other Respecter les indications beachten documentation ci-dessous Achtung! Warning! Attention ! User Manual „Gerätewagen“...
  • Page 2 Elimobil Grundgestell Elimobil base frame Châssis de base Elimobil DEUTSCH ENGLISH FRANÇAIS Rollen Castors Roulettes • Rollen mit Feststeller an den langen • Fit the castors with brakes on the long • Monter les roulettes à blocage sur la Enden der Kufen * montieren (vorn am...
  • Page 3 Danger! Danger ! Maximale Gesamtbeladung des Do not exceed the maximum load Respecter la charge maximale Elimobils beachten: 180 kg of the Elimobil: 180 kg de l’Elimobil : 180 kg Kabelführung Cable routing Passage des câbles • Abdeckkappen oben an den Profilen •...
  • Page 4 Elimobil Grundgestell Elimobil base frame Châssis de base Elimobil DEUTSCH ENGLISH FRANÇAIS • Auf der Rückseite der Quertraverse kann • On the rear of the crosspiece a socket • Au dos de la traverse, il est possible de in zwei Bohrungen eine Steckdosenleiste strip can be fitted in two openings.
