Knurr Elimobil Drawer module Assembly Instructions

Technical furniture

Advertisement

Elimobil – Korpusmodul
Elimobil trolley – Drawer module
Poste mobile Elimobil – Module tiroir
Assembly Instructions
1
Allgemeine Hinweise
Weitere Dokumentation
beachten
Achtung!
User Manual „Gerätewagen" und
Montageanleitung „Elimobil –
Grundgestell" unbedingt beachten.
Gültigkeit
Diese Anleitung gilt für folgende Geräte-
wagen-Komponenten der Knürr AG:
Elimobil Schubfachmodul 1 + 2 und 3
Elimobil Tastaturauszug geschlossen
Notwendiges Werkzeug
Innensechskantschlüssel 4 mm
2
Montage
Schubfach oder geschlossenen Tastatur-
auszug in der gewünschten Höhe
montieren (Lochabstand 25 mm).
A

General information

Refer to the other
documentation
Warning!
See user manual entitled "Mobile
workstations" and assembly instruc­
tions "Elimobil trolley – Base frame".
Validity
These instructions apply to the following
trolley components from Knürr AG:
Elimobil drawer module 1 + 2 and 3
Elimobil closed keyboard shelf
Tools required
4 mm Allen key

Installation

Fit the drawer or closed keyboard
shelf at the required height
(hole spacing 25 mm).
A
A
Technical Furniture
Consignes générales
Respecter les indications
ci-dessous
Attention !
Respecter impérativement le manuel
utilisateur « Postes mobiles » et les
instructions de montage « Poste
mobile Elimobil – Châssis de base ».
Validité
Ce mode d'emploi est valable pour les
éléments de postes mobiles de Knürr AG
suivants :
Module tiroir 1 + 2 et 3 Elimobil
Module tiroir avec tablette télescopique
pour clavier Elimobil
Outils nécessaires
clé Allen 4 mm
Montage
Installer le tiroir ou la tablette téles-
copique fermée à la hauteur désirée
(écartement des trous 25 mm).
4x
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elimobil Drawer module and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Knurr Elimobil Drawer module

  • Page 1 Knürr AG: éléments de postes mobiles de Knürr AG – Elimobil Schubfachmodul 1 + 2 und 3 – Elimobil drawer module 1 + 2 and 3 suivants : – Elimobil Tastaturauszug geschlossen – Elimobil closed keyboard shelf –...
  • Page 2 Elimobil Korpusmodul Elimobil drawer module Module tiroir Elimobil DEUTSCH ENGLISH FRANÇAIS Maximale Beladung Maximum load Charge maximale Gefahr! Danger! Danger ! Maximale Beladung von Schubfach­ Do not exceed the maximum load Respecter la charge maximale modul oder Tastaturauszug beachten: of the drawer module or the keyboard...
