Summary of Contents for Alcor HD-2000
-
Page 2: Table Of Contents
CONTENTS CONTENTS....................2 SAFETY INSTRUCTION................3 FRONT PANEL ..................... 4 REAR PANEL ....................4 REMOTE ....................... 5 PRECAUTIONS ABOUT BATTERIES ............5 PREPARATION OF REMOTE CONTROL ..........8 OPERATION SCOPE OF THE REMOTE CONTROL ....... 8 USEFUL TIPS....................8 SYSTEM CONNECTION................9 1. -
Page 3: Safety Instruction
SAFETY INSTRUCTION IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. -
Page 4: Front Panel
FRONT PANEL 1. POWER switch 2. 3. Volume adjustment/ state alteration 4. 5. Channel up or down/ cursor movement 6. Operation confirmation 7. Menu entry 8. Remote sensor/ status indicator/ displaying board 9. The spot at where to open the lid of mini-door to insert into/ pull off a smart card REAR PANEL 1. -
Page 5: Remote
REMOTE PRECAUTIONS ABOUT BATTERIES Improper use of batteries may cause corrosion or fluid leakage. Please observe the following instructions for the safe use of batteries. 1. Do not mistake the polarities of batteries 2. Never leave dead batteries in the remote control 3. - Page 6 MUTE. Mutes the audio STANDBY. Enters Standby mode or program-watching state FAV. Displays Your Favorites List TV/RAD. Non-menu: to switch program mode between TV and radio LEFT/RIGHT. Menu mode: select or adjust the parameter value; non-menu, volume adjustment UP/DOWN. Menu mode: move the cursor upwards/ downwards; non-menu, channel turning EXIT.
- Page 7 PAUSE. In playing recorded program, time-shifting and recording: freeze/ actuate picture. STOP. In playing recorded program, time-shifting and recording program: exit current mode PLAY. In playing recorded program or time-shifting: to play normally T,T-SHIFT. In watching program, press the key to start timeshift function after a freeze of screen, press the PLAY key to actuate picture.
-
Page 8: Preparation Of Remote Control
PREPARATION OF REMOTE CONTROL Load the batteries to the groove of the remote control and then enable you to operate the native. 1. Open the lid. 2. Load the batteries and attend whether the anode and cathode of battery are corresponding to the polarity indicated on the remote controller. 3. -
Page 9: System Connection
SYSTEM CONNECTION 1. SET UP- YPbPr For this Set Up use an YPbPr lead (Red, Blue Green colored) for the video connection and either the red and white connectors of the RCA leads that came with this Set Top Box or an optical cable for the audio connection. All of video output modes are ready, any type is useful synchronically We do recommend adopting a memory device (a high-speed U disk or a portable HDD) supports interface 2.0. -
Page 10: Set Up-Hdmi
Box. b) Connect the other end of the cable to the corresponding colored connectors on your television monitor. c) Connect the SPIDF for a better audio environment 1.3. Connect the antenna Connect the antenna lead to the “RF IN” connection on the rear of the Set Top Box. -
Page 11: Set Up- Cvbs
2.2. Connecting Video and Audio Video Connect the HDMI cable from the HDMI interface output of the Set Top Box to the HDMI interface input of the TV monitor. Audio Do not link any. The video and audio share just one cord 2.3. -
Page 12: Set Up-Tv Scart
input. Ensure that the power leads to both the TV monitor and the Set Top Box are unplugged before you commence the set up procedure. 3.2. Connecting Video and Audio Video Connect the yellow RCA cable from the VIDEO output of the Set Top Box to the VIDEO input of the TV monitor. - Page 13 Video and audio share one cord 4.2. Connecting Video and Audio Video Connect the TV SCART cable from the TV interface output of the Set Top Box to the TV SCART interface input of the TV monitor. Audio Do not link any. The video and audio share just one cord 4.3.
-
Page 14: Set Up- Amplifier, Home Theater
5. SET UP- Amplifier, home theater For this Set Up use your preferred video connection, the example below shows video connection via YPbPr (component), you can use other methods from the previous examples. You will also need an Optical cable for the audio set up. -
Page 15: Power On
a) Connect the optical cable to the SPDIF connector on the rear of the set top box. b) Connect the other end of the optical cable to the Amplifier. 4.3 Connect the antenna Connect the antenna lead to the RF IN connection on the rear of the Set Top Box. -
Page 16: Menu Tree
MENU TREE... -
Page 17: Scan Channel
SCAN CHANNEL On MAIN MENU, drive the cursor onto the tape of Scan Channel. Press the OK key to enter its submenu. Press the LEFT/RIGHT key to alternate the scan mode between Auto and Manual. AUTO. When on the mode Auto, drive the cursor onto the tape Start Scan;... -
Page 18: User Setting
tape of Frequency (KHz), press the digit-key to input the value, meanwhile, press the [-] key to eliminate the digit, drive the cursor onto the tape of BandWidth (MHz), press LEFT/RIGHT key to switch its status between 7 and 8, ensure that both the tapes of Quality and Strength show their certain length simultaneously, drive the cursor onto the tape of Start Scan, press the OK key to start the scanning;... - Page 19 the marked channel to eliminate the sign. When on the program-enjoying status, press the FAV key to deploy the menu of FAVORITE CHANNEL, similarly, press move cursor, correspondingly, the channel within this type of FAV will list on, pitch on one then press the OK key to watch this channel on its non-menu mode.
- Page 20 EDIT: further, to edit the channel particular. When the cursor stays on the instruction Edit, Press the directional key to opt for channel, press the green key to reveal the dialog box of Edit Program: move the cursor onto the instruction V.PID, A.PID, PCR.PID, TTXT.PID in turn, press the [-] key and the digit-key to modify its parameter;...
- Page 21 Language Setting: after entering the LANGUAGE SETTING, Press the LEFT/RIGHT select menu language. Note, on the instruction Menu Language, which category is being opted means that it owns the strongest priority in broadcasting. A/V Output Setting: after entering the A/V OUTPUT SETTING, press the directional key to adjust.
- Page 22 Output Mode. Press the LEFT/RIGHT key to select HD video mode. 1080I@50, 1080I@60, 720P@50, 720P@60 or 576P@50. Those above just work on the HD video output. On this receiver embody as HDMI and COMPONENT VIDEO outputs. Output Switch. YPbPr and RGB. Use to switch the video output work on COMPONENT VIDEO and TV scart.
- Page 23 then, input the new one and then, input which to verify, when phrase “PIN changed” appears show that modification has made. When instruction Lock Menu is locked, to reveal menu needs code input Parental Lock. Set limitation class based on age. No, unlimited; ALL, block all.
- Page 24 MP3. After entering, press directional key to opt item, press the [OK]/ to play, press yellow key to pause/ play, press the green key to change playing order among random, circular and order, press the key to display its properties, press the [EXIT] key to quite. USB Format.
- Page 25 means device been connected fully. Disconnect the device by using the instruction [USB Uninstall] in USB SETTING. Press the [MENU] key to get into [Main Menu], opt for [User setting] instruction and enter, pitch on [PVR Setting] and get into. Image shows as right side.
- Page 26 In playing the recorded program, press the [PAUSE] key to still or restore playing, press the [STOP] key to exit, press the [INFO] key to display present relative information, press the [SLOW] key repeatedly to slow down performance speed X1/2, X1/4,X1/8,X1/16,X1/32, press the key [PLAY] to perform normally, press the key [FF] repeatedly to speed up performance at the speed of X2, X4, X8, X16, X32, press the key [PLAY] to perform normally.
- Page 27 Press the green key to enter [Add Pvr Timer] to add an item to be prerecorded. Record Pro: move the cursor onto this instruction, press the key to list program list, and press the digit-key and directional key to set Date Start and Time Start and time length (minute) to be recorded (Duration), press the [OK] key on [Confirm] to confirm.
-
Page 28: Tv Channel
On the state of program-watching, press the key [T-SHIFT/T] to start time-shifting function, the screen displays helping information bar meanwhile, the live picture come to still. During this process, press [PAUSE] repeatedly pause restore time-shifting function; press the key [STOP] to terminate shift, press the key [INFO] display present... -
Page 29: Radio Channel
RADIO CHANNEL Same operation as TV CHANNEL’s EPG INFORMATION On MAIN MENU, after highlighting [EPG Information], press the OK key to enter. As well as, by pressing the EPG key on the program-watching state can get into EPG interface. On channel column, press the directional key to select one of, press the key to watch it on the small window, press the... -
Page 30: Something Else
PVR Order. Use to book to a program to be pre-recorded. The receiver will jump to the booked program to record it when the time is up. EPG&Standby. Use to book a program without pre-recording; even if the receiver stays its standby mode, it’ll be awaked up and turn to the booked program. - Page 31 AUDIO FORMAT. program-watching state, press the key [AUDIO] to display a dialog box [Audio CTL], press the key to pitch on [AUDIO FORMAT], press the key [OK] to enter its submenu, press the key to select an option between [PCM, COMPRESSED], press the key [OK] to confirm, meanwhile, a symbol # will be added before the option.
- Page 32 transparent; re-press the TTX key to render the background on opaque. Press the ▲ key to turn page forwards and press the ▼ key to turn page backwards. The information of date and time are presented on the top right corner. Press the EXIT key to withdraw the mode of graphics context.
- Page 33 Explication of pre-recording startup when standby The prerequisite of pre-recording startup when standby is that the receiver has detected the time data from the signal it received. I.e. the systemic time is the available time. Given an unavailable time, nor did the pre-recording startup when standby.
-
Page 34: Specification
SPECIFICATION Tuner Input Frequency 146 MHz - 862 MHz VHF High Band: 149.5 to 426MHz UHF Band: 434 to 858MHz Input Signal Level -87dBm to -20dBm Input impedance 75 ohm Loop Through Output Impedance 75 ohm RF Input connector IEC type Female RF Output connector IEC type Male Modulations Modes... - Page 35 PAKING LIST ITEM QUANTITY REMARK DIGITAL RECEIVER REMOTE MANUAL BATTERY AV LINE...
