MANEBROH
0 07EN
5K
U S E R
M AN U A L
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spuma Li 5K and is the answer not in the manual?

Questions and answers

Related Manuals for E-Broh Spuma Li 5K

Summary of Contents for E-Broh Spuma Li 5K

  • Page 1 MANEBROH 0 07EN U S E R M AN U A L...
  • Page 2 Thank you for buying your Electric Scooter. In order to keep your scooter in working condition, before use please read these instructions carefully. The scooter has an attractive and stylized design. All our electric scooters have a reliable and safe structure. They stand out for their easy handling and are equipped with a top quality engine.

  • Page 3: Warnings To The User

    W AR N IN G S TO T HE U S E R 1. Please read this manual carefully before using the vehicle for correct use. 2. Please check carefully that the components are listed as indicated in the product manual before use your vehicle for safety reasons. 3.

  • Page 4: Safety Advice

    SA F ET Y AD VI CE 1. Using biker equipment is important. The use of an approved helmet is essential. 2. Meet your Spuma Li. Your driving skills and mechanical skills are the foundation for safe driving. It is recommended to practice in open spaces, quiet roads, and know the mechanical performance and handling first.

  • Page 5: Table Of Contents

    I ND EX O F C ON T EN TS 1. Warnings to the user 2. Precautions 3. Safety advice 4. Modifications to the vehicle + Nº VIN 5. Operating and running instructions 10. Warranty policy 6. Display information 11. Technical information 7.
  • Page 6 M ODI F I CAT I ONS TO TH E VE H IC LE Conversions or additions can leave your vehicle unprotected and could put you and other road users at risk. They can be carried out only where they are legally permitted. Ask your dealer if they are allowed when buying or choosing original accessories. Modifying the engine, controller, or battery is illegal.
  • Page 7 OP ER ATI NG AND DR I V IN G IN STR UC TIO N S Inspection before movement In accordance with road traffic regulations, the driver is responsible for the conditions of his vehicle. The essential properties of your vehicle can change even after a short stop.
  • Page 8 CH ECK BE FO R E C I RC U LAT ING What to check Passwords 1. Constancy. Steering 2. Flexible handlebar. handlebars 3. No axle shift or loose. 1. Brake control has between 5 to 9 mm of unused travel. Brake 2.
  • Page 9 D A T A FR OM T HE DIS P LA Y Depending on the model 1. Left turn 7. Battery percentage 2. Right turn 8. Failure of the accelerator control 3. High beam 9. Brake failure 4. Indication of stop or parking (depending on model) 10.
  • Page 10 IN FOR MA C IÓ N DE LOS COM P ONENTES...
  • Page 11 1. LED headlight 2. Front shock absorber 3. Battery 4. Rear rack 5. Rear light 6. Rear flashing LED lights 7. Motor brushless 8. Rear flashing LED lights 9. Rear Reflector 10. Brake control 11. Passenger foot stand 12. Front brake disc 13.

  • Page 12: Operations Guide

    OP ER ATI ONS GUI DE ENVIRONMENTAL USE OF THE BATTERY The battery is ready to be used in an ambient temperature range of -10ºC a 45ºC. Do not expose the battery to corrosive water, beverages, or liquids to prevent leakage, overheating, smoke, fire, or explosions. Do not store the battery near a source of heat, fire, flammable and explosive gases and liquids, metal objects in the battery compartment may cause spills, overheating, smoke, or explosions.
  • Page 13 W AR N IN G The lithium battery is a type of consumable, the correct method of use can extend the useful life of the lithium battery. Vehicles must be charged immediately after each use of the lithium battery, rather than waiting for the lithium battery to recharge after the power is less than 20%.

  • Page 14: Start

    STARTER Shutdown Open the trunk Open the trunk Restart Block directional Ignite scooter Insert the key into the lock and turn it. Off and on to open and lock the trunk. Turn to lock the steering handlebars.
  • Page 15 LEFT CONTROLLER 1. Long and short lights 2. Direction indicator 3. Claxon Luces largas Long and short lights. Press the top to turn on the long lights; press the bottom to turn on the short lights. Luces cortas Direction indicator. Push the button to the left to turn left.
  • Page 16 RIGHT CONTROLLER 1. Light parking lot emergency 2. Motor switch 4. Front brake 3. Reverse 5. Handlebar 6. Shift 7. Button maintenance...
  • Page 17 CL EAN I NG AN D CA R E Regular and proper cleaning is an important factor for the maintenance of your vehicle. It is important to maintain the full functioning of the main parts of the vehicle. 1. Place the vehicle on the main stand for cleaning. 4.

  • Page 18: Control

    PE RI OD I C MAI N T ENAN CE LIST Regular safety and Brake Checking of Bearing of the wheels performance testing the structure Lights Damping Claxon Parking feet Electrical components Steering bearing Fuse Checking of the Battery main parts Wheels Main wiring Structure check...
  • Page 19 PE RI OD I C MAI N T ENAN CE LIST Description Cause Troubleshooting of the judgment 1. Loose wires. 1. Check the loose wire. Failures displayed in 2. Damage to the communication device. the control panel. 2. Send the Ebroh scooter to service for checking by a professional.
  • Page 20 Regular maintenance. The first maintenance must be done one month after purchase or after traveling a distance of 500Km. After this especially the control and maintenance must be taken to our after-sales services every 6 months or 3000km. A control and maintenance have as objective the safety of the scooter Ebroh and the driver. ATTENTION.
  • Page 21 Cleaning of the Ebroh scooter. Please use a hose and clean Ebroh scooter with running water and neutral detergent. Dry the Ebroh scooter with a soft cloth that does not scratch the surface. DANGER. Never use pressurized water to wash the Ebroh scooter. Do not wash the sides, back or inside of the battery compartment with pressurized water.
  • Page 22 MAINTENANCE PROGRAM The inspection intervals specified in the maintenance programme are applied to use the vehicle in normal use. Maintenance intervals may need to be shortened depending on location, weather conditions, personal driving style and terrain. The first event (month or kilometers) is decisive. Adjustment: A, Change: C, Inspection: I (includes lubrication, adjustment, cleaning or change of component in case of wear or damage if necessary) After 1 month...

  • Page 23: Inspection Log

    INSPECTION LOG Inspection and maintenance work can only be performed and confirmed by an authorized dealer. The first maintenance (month or kilometers) is decisive. 1º Inspection and maintenance 2º Inspection and 3º Inspection and maintenance 4º Inspection and maintenance after 1 month or 500 km. maintenance after 12 months after 2 years or 8000 km.

  • Page 24: Warranty Policy

    W AR R AN T Y POL I CY All our Ebroh scooters are guaranteed by manufacturing defects for 24 months from the time of delivery. All wear-resistant components such as brake pads, tyres, shafts, bearings and light bulbs are excluded from the warranty. The security shall be cancelled if any of the following conditions is met: - Where a malfunction attributable to human error or negligence of the machine user is demonstrated.

  • Page 25: Technical Information

    T E CHN ICA L INFO R M A TI O N MA I N F EAT UR E S SAMSUNG Ion Litio removable x2 80 Km / h Battery Maximum speed 70 V 200 Kg Voltage Maximum load 2 approved persons Capacity 1160 mm 690 mm...
  • Page 26 BOSCH 4700 W Motor Type Brushless 35 A / 45 A Maximum current of the controller Battery type SAMSUNG Ion Litio REMOVABLE 70V / 20Ah Voltage / capacity 12,5 Kg Battery weight Normal charging current 40 A Maximum load current Structure Brake Disk...

  • Page 27: Vehicle Authorisation

    VE H I CL E AU T HOR I S A TI ON Please fill in next to the guarantee card. Type. Nº key. Structure Nº. Color. Name. Last name. Postal Code - City. The Scooter was successfully delivered by: Date of Signature / stamp Buyer’s...

  • Page 28: Warranty Card

    W AR R AN T Y CA RD Type. Nº ignition key. Structure Nº. Color. Name. Last name. Postal Code - City. The Scooter was successfully delivered by: Date of Signature / stamp of Buyer’s purchase. the distributor. signature.

  • Page 29: Maintenance Record Sheet

    M AI N T E NAN CE R ECOR D SH E E T Cause and Date procedure for Person Fault Description Place of service OBSERVATIONS dd/mm/aa resolving the of service judgement...
  • Page 30 M AI N T E NAN CE R ECOR D SH E E T Cause and Date procedure for Person Fault Description Place of service OBSERVATIONS dd/mm/aa resolving the of service judgement...
  • Page 31 M AI N T E NAN CE R ECOR D SH E E T Cause and Date procedure for Person Fault Description Place of service OBSERVATIONS dd/mm/aa resolving the of service judgement...
  • Page 32 www.ebroh.es Of i c i n a · + 34 8 7 6 7 6 8 0 4 0 info@ebroh.es...
