  • Page 1 Manual: PASION and PASIONE electric bikes.
  • Page 3: Table Of Contents

    Content 1. safety and annotations ..................................................4 2. basic structure and names ................................................6 3. dimensiones and distances ................................................7 4. display and control engine and battery ........................................8 5. battery and taillights ..................................................9 6. folding the ebike ......................................................10 7.
  • Page 4: Safety And Annotations

    1. safety and annotions Bicycles with electric force, are fitted with pedals and an auxiliary electric motor, which can not propel exclusively. Compared with bicycles, Ebikes include a motor, controls, and battery charger. When circulating, electric power saving helps circulate easily work.
  • Page 5 • In the process of use, pay attention to check the condition of the motor mountings and the damper fork, and if you notice them loose, you must tighten them correctly. • When starting an acceleration or a slope, pedal as far as you can to help reduce battery drain and lengthen assisted mileage. •...
  • Page 6: Basic Structure And Names

    2. basic structure and names 2.1 structure of urban pasion - ebike pasione 1. CARBON FRAME 11. REAR DISK BREAK 21. VAL VE 2. TILE (Seatpost) 12. FRONT HUB 22. FRONT BREAK 3. SEAT 13. RIM 23. REAR BREAK 4. STEEM 14.
  • Page 7: Dimensiones And Distances

    3. 3. dimensions and distances...
  • Page 8: Display And Control Engine And Battery

    4. display, engine and battery control data: displayed information display segment lcd Battery level indicator nominal voltage 24/36/48 V Motor output indication comunication uart / lin / can Assistance level indication assistance modes 0-5 / 0-7 / 0-9 Speed indication (incl. current cover colours black / White speed, Max.
  • Page 9: Battery And Taillights

    5. battery and rear lights 1. CHARGER PLUG 2. OUTPUT DC 5V 3. LEFT/RIGHT BLICKING LIGHT 4. TRANSPORT AND EXTRACTION HANDLE...
  • Page 10: Folding The Ebike

    6. ebike folding 1. Fold the pedals to the crank arm. 2. From the left side of the bike (dismount the bike) press the FOLDING UNLOCK BUTTON and release the LEVER FOR LOCK/FOLDING FRAME. 3. Take with the right hand the saddle and with the left hand the HANDLE or the HEADSET.
  • Page 11: Technical Characteristics

    7. technical characteristics MOTOR: 36v MAX. 250W brushless BATTERY: SAMSUNG lITIO 8.7Ah. (removable) DISPLAY: KBY-DISP on/off, charge, 5 levels, speed, kilometers... DERAILLEUR: SHIMANO SORA 9V BREAKS: SHIMANO M315 CHAIN: KMC CRANKSET: 170 MM. WHEEL: 20’’ WEIGHT: 15 KG.
  • Page 12: Use And Maintenance

    8. use and maintenance 5.1 rutinary check before use the bicycle. 1. Install the battery in the battery guides and be sure it is well adjusted and locked. Press start button in the battery and check that the electronic system is on. 2.
  • Page 13: Troubleshooting

    9. troubleshooting failure cause solution Failure to change speed or too slow maximum 1. Battery discharged or low. 1. Charge the battery fully. speed. 2. Command failure. 2. Replace the remote. 3. Engine control failure. The motor is on but it does not work. 1.
  • Page 14: Recommendations

    11. recommendations use of the brakes. When driving in wet or rainy conditions, braking can be affected, so you must anticipate a greater distance of braking and a lower speed. The surface of the brake disc must not be lubricated. It can make the pads do not brake. If the braking cable is torn, it may end up breaking.
  • Page 15: Road Safety

    12. road safety. Observe national and local traffic safety regulations. The Traffic and Road Safety Law, on May 9, 2014, the use of the helmet will always be mandatory for children under 16, whether drivers or occupants of the bike. This rule does not distinguish the way in which they circulate. For those over 18 it will be mandatory on interurban roads.
  • Page 16 Oficina · +34 876 768 040 info@ebroh.es www.ebroh.es Plataforma Logística Zaragoza PLAZA - c/ Tarento, 9 - 50197 - Zaragoza (Spain)
