ILLUSTRATED PARTS CATALOG
Designs, materials, weights, specifications, and dimensions for equipment or replacement parts
are subject to change without notice.
BUNN-O-MATIC CORPORATION
POST OFFICE BOX 3227
SPRINGFIELD, ILLINOIS 62708-3227
PHONE: (217) 529-6601 FAX: (217) 529-6644
www.bunn.com
37485.0000C 12/06 ©2004 Bunn-O-Matic Corporation

Advertisement

Table of Contents
loading

Related Manuals for Bunn MCA

Summary of Contents for Bunn MCA

  • Page 1 ILLUSTRATED PARTS CATALOG Designs, materials, weights, specifications, and dimensions for equipment or replacement parts are subject to change without notice. BUNN-O-MATIC CORPORATION POST OFFICE BOX 3227 SPRINGFIELD, ILLINOIS 62708-3227 PHONE: (217) 529-6601 FAX: (217) 529-6644 www.bunn.com 37485.0000C 12/06 ©2004 Bunn-O-Matic Corporation...
  • Page 2 (at our exclusive option) either (1) arrange for the unit to be repaired, at no cost to you for parts or labor, by a Bunn Authorized Service Representative, (2) replace the unit at no charge to you or (3) refund the purchase price you paid for the unit.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS RESERVOIR, CHECK VALVES, TUBES, PUMPS & SOLENOID ... 8 ELECTRICAL & OPERATING CONTROLS ... 12 SPRAYHEAD ASSEMBLY ... 14 POD HOLDER ... 16 HOUSINGS & COVERS ... 4 NUMERICAL INDEX ... 18 TANK & COMPONENTS ... 6 37485 112304...

  • Page 4: Housings & Covers

    HOUSINGS & COVERS P3051.65 37485 091305...
  • Page 5 ITEM PART NO. QTY. 37495.1000 37491.0000* 36272.0000* 36262.0000* 01360.0001 36265.0001* 36322.0000* 36261.0000* 36726.0001* 36724.0003* 34466.0000 37520.0001 36269.0002 36727.0000 36990.0000* 37282.0000 37281.0000 37267.0000 00656.0000 37092.0001 37519.0001 * Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement. HOUSINGS &...

  • Page 6: Tank & Components

    TANK & COMPONENTS Complete Assembly P3055.75 37485 112304...
  • Page 7 ITEM PART NO. QTY. 36289.0001 36289.0002 37725.0001* 37725.0002* 36396.0001* 38184.0000* 36895.0000* 37061.0000* 37083.0000 * Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement. TANK & COMPONENTS DESCRIPTION Tank Assembly, 120V, 1450 W W/Leads (Includes Items 2 Through 6) Tank Assembly, 230V, 1450 W W/Leads (Includes Items 2 Through 6) Tank Weldment, Main 120V 1450 W Tank Weldment, Main 230V 1450 W...

  • Page 8: Reservoir, Check Valves, Tubes, Pumps & Solenoid

    RESERVOIR, CHECK VALVES, TUBES, PUMPS & SOLENOID Strainer Assy 230V Models Early Models P3053.65 37485 122806...
  • Page 9 RESERVOIR, CHECK VALVES, TUBES, PUMPS & SOLENOID ITEM PART NO. QTY. 37419.1000 36264.0000 36321.0000 36316.0000 36378.0001 36629.0000 36329.0002 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 36630.0000...
  • Page 10 RESERVOIR, CHECK VALVES, TUBES, PUMPS & SOLENOID Strainer Assy 230V Models Early Models (Continued) P3053.65 37485 122806...
  • Page 11 RESERVOIR, CHECK VALVES, TUBES, PUMPS & SOLENOID ITEM PART NO. QTY. 37094.0000 37925.0000 37452.0000 38414.0000 37469.0000 37470.0000 37489.0000 22249.0000 38413.0000 23721.0000 ------------- 22307.0222 20526.1222 01155.0000 01154.0000 36329.0002 00310.0000 00935.0001 39182.0000 39216.0000 39446.0000 * Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement. DESCRIPTION Fitting, Quick Disconnect .25”...

  • Page 12: Electrical & Operating Controls

    ELECTRICAL & OPERATING CONTROLS 16 7 P3050.60 37485 122806...
  • Page 13 ITEM PART NO. QTY. - - - - - - - - 36903.0000 38316.0000* 36382.0000 37084.0000 37084.0002 38386.0000 36285.0000 36901.0000 36891.0000 36270.0001* 37522.0001 37522.0005 36171.0001* 38302.0003* 37035.0000 36381.0000 36381.0001 36381.0002 06064.0000 36718.0000 37949.0000 38955.0000* 36546.0000 36547.0000 21001.0725 * Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement. ELECTRICAL &...

  • Page 14: Sprayhead Assembly

    SPRAYHEAD ASSEMBLY P3054 37485 122806...

  • Page 15: Sprayhead Assembly

    ITEM PART NO. QTY. 37418.0000 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 36278.0000* 36532.0000* 36279.0000* 01360.0001 36536.0000 37543.0000*...

  • Page 16: Pod Holder

    POD HOLDER P3052.70 37485 122806...

  • Page 17: Pod Holder

    Decal, Hot Liquids Kit, Accessory (Includes Items 6, 9, 11, 13, 14 & 15) Descaler, Urnex (Available at Web Site - www.bunn.com) (Not Illustrated) Descaler, JavaClean2 (Available at Web Site - www.bunn.com) (Not Illustrated) Drip Tray (Not Illustrated) (See “Housings & Covers”) Grate, Drip Tray (Not Illustrated) (See “Housings &...

  • Page 18: Numerical Index

    PART NO. PAGE NO. PART NO. 00310.0000... 11 36629.0002... 9 00656.0000... 5 36630.0000... 9 00935.0001... 11 36631.0001... 9 01154.0000... 11 36631.0002... 9 01155.0000... 11 36631.0003... 9 01360.0001... 5,9,15 36715.0000... 17 06064.0000... 13 36716.0000... 17 20526.1222... 11 36716.0001... 17 20001.0725... 13 36717.1000...
