OLI High vision User Manual

Hide thumbs Also See for High vision:
Table of Contents

Advertisement

Quick Links

IT
original instructions
USER MANUAL
High vision
00_112020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the High vision and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for OLI High vision

Summary of Contents for OLI High vision

  • Page 1 USER MANUAL High vision 00_112020...
  • Page 2 MAINTENANCE AND ASSISTANCE Walk mode INSTALLATION Technical assistance eBike light adjustment Cleaning and maintenance Display installation Menu Keypad installation Reset trip Transport, packaging and storage System info © Copyright Oli eBike Systems · revision 00_112020 · Graphics and layout studioimmagina.com...

  • Page 3: Purpose Of The Manual

    It is recommended to read this manual carefully opening it with the free Adobe reader software before putting the unit into operation. (https://get.adobe.com/it/reader/). With a view to continual improvement, OLI eBike The icon indicates additional interactive areas Systems may change some characteristics of the other than those listed above.

  • Page 4: Troubleshooting

    OLI eBike Systems | High Vision MANUFACTURER CERTIFICATION GENERAL OLI eBike System is at your disposal for any problem The unitHIGH VISION was made in compliance with INFORMATION or information. the relevant Community Directives applicable at the Communications and requests can be sent to:...

  • Page 5: Warranty

    OLI eBike Systems | High Vision WARRANTY SAFETY RULES GENERAL The unit is covered by a warranty on materials for In order to minimize the causes that can create INFORMATION a period of 36 months from the date shown on the dangerous situations for users and others, we invite shipping document.

  • Page 6: General Description

    OLI eBike Systems | High Vision GENERAL DESCRIPTION GENERAL HIGH VISION is an HMI unit that allows you to analyse The unit consists of the following components: INFORMATION and view data relating to the eBike and the training in progress.

  • Page 7: Technical Data

    OLI eBike Systems | High Vision TECHNICAL DATA GENERAL INFORMATION Display type Dot matrix LCD Operating temperature -5°C / 40°C DESCRIPTION Storage temperature -20°C / 60°C INSTALLATION Degree of protection IP 67 SIZES AND OVERALL DIMENSIONS TROUBLESHOOTING MAINTENANCE AND ASSISTANCE...

  • Page 8: Display Installation

    OLI eBike Systems | High Vision DISPLAY INSTALLATION GENERAL 1 > Insert the display holder rings on the handlebar. INFORMATION DESCRIPTION INSTALLATION 2 > Install the display on the support, tightening the M4 fixing screws. TROUBLESHOOTING MAINTENANCE AND ASSISTANCE 1.5 - 3 Nm...
  • Page 9 OLI eBike Systems | High Vision GENERAL 3 > Position the display on the supports paying INFORMATION attention to the angle (15 ° - 35 ° with respect to the horizontal plane) and tighten the fixing screws with the nuts.

  • Page 10: Keypad Installation

    OLI eBike Systems | High Vision KEYPAD INSTALLATION GENERAL 1 > Position the keypad while paying attention to the INFORMATION angle (15 ° - 35 ° with respect to the horizontal plane), so as to allow the user to operate it comfortably while moving.

  • Page 11: Transport, Packaging And Storage

    OLI eBike Systems | High Vision TRANSPORT, PACKAGING AND STORAGE GENERAL The unit is supplied with dedicated packaging which INFORMATION avoids damage from transport. Upon receipt of the goods, the customer must check whether the model and quantity received correspond DESCRIPTION to the data in the order confirmation.
  • Page 12 OLI eBike Systems | High Vision COMMANDS GENERAL To navigate the software there are 3 keys that can be INFORMATION used with short press or with a press of more than 2 seconds. Throughout this manual, the following icons are used DESCRIPTION to indicate the type of key and press for each action.

  • Page 13: Navigation Diagram

    OLI eBike Systems | High Vision NAVIGATION DIAGRAM GENERAL INFORMATION POWER OFF POWER ON DESCRIPTION Distance ADVANCED INSTALLATION Time Brightness Language Pace HOME Reset Trip Unit MENU Power Advanced Weight ADVANCED System Info Gender Race TROUBLESHOOTING Battery Info Mod. Night...
  • Page 14 OLI eBike Systems | High Vision POWER ON GENERAL To turn on the display, depending on the type of INFORMATION battery installed: › press and hold the power-on key until the power-on screen with the manufacturer's logo is displayed or DESCRIPTION press the on key on the battery.
  • Page 15 OLI eBike Systems | High Vision HOME GENERAL After powering on, the first Distance screen of the From any screen in the Home section, you can: INFORMATION › Home section is displayed. adjust the assistance level by pressing the up The Home section consists of 6 screens.
  • Page 16 OLI eBike Systems | High Vision General screen layout GENERAL The screens in the Home section differ from each INFORMATION other in the type of information displayed. eBike light adjustment automatic / on / off see “eBike light adjustment “on DESCRIPTION pg.
  • Page 17 OLI eBike Systems | High Vision GENERAL The first 4 screens differ only for the variable parameter which is described below. INFORMATION To reset the datasee “Reset trip “on pg. 24 . For other screen datasee “General screen layout “on pg.
  • Page 18 OLI eBike Systems | High Vision "Race" screen GENERAL It is the fifth screen of the Home section. INFORMATION pace In this screen, the values in watts (w) of the motor power and cyclist power are expressed in full. assistance...
  • Page 19 OLI eBike Systems | High Vision Summary screen GENERAL It is the sixth screen of the Home section. INFORMATION This screen summarizes the variable parameters of the previous screens. DESCRIPTION Indicates the distance travelled in kilometres (km) since the last reset.
  • Page 20 OLI eBike Systems | High Vision Assistance level GENERAL From any screen in the Home section it is possible to INFORMATION change the assistance level by pressing the up key to increase it and the down key to decrease it.
  • Page 21 OLI eBike Systems | High Vision Walk mode GENERAL The system is equipped with a walk assistance function, INFORMATION which allows you to activate the motor up to a maximum speed of 6 km / h, allowing you to tackle short stretches more easily by pushing the eBike.
  • Page 22 OLI eBike Systems | High Vision eBike light adjustment GENERAL The lights of the eBike can be adjusted in four INFORMATION different ways: › automatic off (default setting at power-on), automatic shutdown takes place automatically by means of DESCRIPTION the twilight sensor integrated in the HMI which automatic detects the ambient brightness level;...
  • Page 23 OLI eBike Systems | High Vision MENU GENERAL From the Home section, hold down the up + down keys From the Menu page: INFORMATION › at the same time for 2 ”to enter the Menu section. use the up and down keys...
  • Page 24 OLI eBike Systems | High Vision Reset trip GENERAL The Reset trip item allows you to reset all the recorded INFORMATION MENU lap data by returning the counters to zero (0). By pressing the power-on key it starts immediately upon reset.
  • Page 25 OLI eBike Systems | High Vision ADVANCED GENERAL From the Advanced page: › From the Menu section it is possible to access the use the up and down keys to scroll through INFORMATION Advanced section by selecting the relevant item.
  • Page 26 OLI eBike Systems | High Vision Screen brightness GENERAL From this screen, you can adjust the brightness of the INFORMATION screen. minimum brightness Use the up and down keys to scroll through the DESCRIPTION values from 1 to 10. The selected value is highlighted in the centre in the white line.
  • Page 27 OLI eBike Systems | High Vision Language GENERAL From this screen you can choose the language of the INFORMATION unit's text. LANGUAGE Use the up and down keys to scroll through DESCRIPTION Italiano the available items. The selected value is highlighted in the centre in the white line.

  • Page 28: Measure Unit

    OLI eBike Systems | High Vision Unit of measure GENERAL From this screen it is possible to select the unit of INFORMATION measure with which the following are calculated: MEASURE UNIT › instantaneous speed, › average speed, DESCRIPTION › average consumption, ›...
  • Page 29 OLI eBike Systems | High Vision Weight GENERAL From this screen you can set your body weight by INFORMATION choosing a value between 50 and 150 kg. WEIGHT Setting this datum is not necessary for the DESCRIPTION min 50 Kg eBike to function correctly.
  • Page 30 OLI eBike Systems | High Vision Gender GENERAL From this screen you can set your gender. INFORMATION GENDER Setting this datum is not necessary for the eBike to function correctly. The value has the DESCRIPTION sole purpose of making the calculation of the calories consumed reliable.

  • Page 31: Night Mode

    OLI eBike Systems | High Vision Night mode GENERAL From this screen you can choose the configuration INFORMATION for night mode: NIGHT MODE › automatic, the night mode is set automatically by means of the twilight sensor inside the display,...

  • Page 32: Error Codes

    DESCRIPTION Where "request assistance" is indicated, the The following table lists the possible faults and the intervention of an OLI eBike Systems technician is required. 4-character codes displayed in the error messages. INSTALLATION error...
  • Page 33 OLI eBike Systems | High Vision GENERAL error problem solution INFORMATION 0105 Request assistance. Non-compliant torque meter signal. The torque meter signal has a fault. Reduced power operation. DESCRIPTION 0106 Non-compliant torque meter offset. The Request assistance. torque meter signal has a fault.
  • Page 34 OLI eBike Systems | High Vision GENERAL error problem solution INFORMATION 0809 The battery voltage is higher than the Possible battery defect, try alternative or new maximum allowed. battery. DESCRIPTION 0810 Request assistance. Non-compliant current sensor signal. 0811 Request assistance.

  • Page 35: Technical Assistance

    OLI eBike Systems | High Vision TECHNICAL ASSISTANCE GENERAL The manufacturer declines all responsibility for damage to persons or property, as well as for Ordinary and extraordinary maintenance must be INFORMATION the faulty operation of the unit, in the event of: carried out in accordance with the instructions contained in this manual.

  • Page 36: Cleaning And Maintenance

    OLI eBike Systems | High Vision CLEANING AND MAINTENANCE GENERAL Do not dispose of the various components in None of the components must be immersed in water household waste. Do not throw this product into the INFORMATION or cleaned with a high-pressure jet.
  • Page 37 Delete this page in the digital version...
  • Page 38 OLI eBike Systems Tel +39 0547 318322 visit our website Via delle pesche, 891 Via delle pesche, 891 info@oli-ebike.com info@oli-ebike.com 47522 Cesena (FC) Italy 47522 Cesena (FC) Italy customerservice@oli-ebike.com customerservice@oli-ebike.com www.oli-ebike.com www.oli-ebike.com...
