Space Seating 525-3G3N11 Operating Instructions

525-3G3N11 / 525-E3G3N11 / 525-G33N11
ÉTAPE 1 ÉTAPE 2
13
9
2
X5
1
8
ÉTAPE 4 ÉTAPE 5
13
11
X3
4
12
6
Enlever toutes les pièces du carton, les organiser selon les numéros de pièce indiqués sur la liste et vérifier les quantités des pièces.
ÉTAPE 1 Insérer les cinq roulettes (2) dans la base (1). Pousser fermement jusqu'à ce que les roulettes (2) s'encliquettent.
ÉTAPE 2 Fixez les Bras (7L et 7R) au coussin du siège (5) avec trois rondelles plates (8) et trois vis de bras (9) pour chaque bras (8). SERREZ
TOUTES LES VIS AVEC LA CLÉ ALLEN (13).
ÉTAPE 3 Fixer le plaque du siège (4) au coussin du siège (5) avec la flèche vers l'avant de la chaise à l'aide de quatre vis de plaque
du siège (10). SERREZ TOUTES LES VIS AVEC LA CLÉ ALLEN (13).
ÉTAPE 4 Fixer le support du dossier (12) à l'arrière du plaque du siège (4) avec les vis de support de dossier (11). SERREZ TOUTES LES VIS
AVEC LA CLÉ ALLEN (13)
ÉTAPE 5 Placer le siège assemblé sur le dessus du vérin pneumatique (3) et pousser vers le bas.
ATTENTION: AVANT D'UTILISER LE FAUTEUIL, S'ASSURER D'AVOIR SERRÉ COMPLÈTEMENT TOUTES LES VIS.
FAUTEUIL DE DIRECTION
INSTRUCTIONS DE MONTAGE
ÉTAPE 3
13
9
X3
X3
10
8 X3
X3
5
7L
5
7R
PIÈCE
1. Base . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2. Roulettes . . . . . . . . . . . . . . . . . . . . . . . 5
3. Vérin pneumatique . . . . . . . . . . . . . . . 1
4. Plaque du siège . . . . . . . . . . . . . . . . . 1
5. Coussin du siège . . . . . . . . . . . . . . . . 1
6. Dossier . . . . . . . . . . . . . . . . . . . . . . . . 1
7. Bras (7L et 7R) . . . . . . . . . . . . . . . . . . 2
8. Rondelles plates . . . . . . . . . . . . . . . . . 6
9. Vis de bras . . . . . . . . . . . . . . . . . . . . . 6
10. Vis de plaque du siège . . . . . . . . . . . 4
11. Vis de dossier . . . . . . . . . . . . . . . . . . 3
3
12. Support de dossier (préinstallé) . . . . 1
13. Clé allen . . . . . . . . . . . . . . . . . . . . . 1
1
X4
4
3
1
QTÉ
525-E3G3N11 & 525-G33N11
(not shown)

SPACE LIMITED WARRANTY

SPACE® chairs are warranted* from the date of purchase against failure due to material and workmanship as follows:
• Lifetime on component parts including pneumatic cylinder, control mechanism, base and casters.
• 3 Years on upholstery fabric and foam against wear and deterioration.
To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and obtain return authorization.
At it's option Office Star Products will:
(a) Supply compatible components of current manufacture.
(b) Repair the customer's component. The customer must prepay freight on any components returned to the factory. Return freight on components
still in warranty will be paid by Office Star Products.
*All warranties are limited to the original purchaser for normal commercial usage defined as a standard forty hour work week by persons weighing 250 lbs.
or less. The 63-37A773HM, 75-7A773, 75-37A773, 75-47A773 and 839-11B35WA are for persons weighing 400 lbs. or less, the 818 & select 829's with self-
adjusting mechanism are 300 lbs. or less and the 15-37A720D is 325 lbs. or less. This warranty will not cover labor, freight or damage from misuse, abuse,
negligence, alteration, accident, vandalism, rusting, acts of nature or any other event beyond the control of Office Star Products. The warranty does not cover
cosmetic damage that may result from normal use. Liability for incidental or consequential damages is excluded. The user assumes all risk of injury resulting
from use of this product. When usage is more than 40 hours per week, a five year warranty on all parts applies. Fabric is warranted for one year. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state.
All Space chairs meet or exceed ANSI BIFMA standards.
It is the customer's responsibility to prepay freight on any components returned to the factory. Return freight on components covered by warranty
will be paid by Office Star Products.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts are damaged or missing. Our
Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail parts@officestar.net, by Fax 1-909-930-5629, or toll free
parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00 p.m. Pacific Time.
© Office Star Products mai 2015
525-3G3N11 / 525-E3G3N11 / 525-G33N11
MANAGER'S CHAIR
OPERATING INSTRUCTIONS

FEATURES

• PNEUMATIC SEAT HEIGHT ADJUSTMENT

To raise seat remove pressure from seat and lift
lever (1). To lower seat height sit on chair and lift lever (1).
NOTE: It is normal for chair to slightly lower under body weight.

• 2-TO-1 SYNCHRO TILT ADJUSTMENT

For individual comfort, this chair has been equipped with an
adjustment knob that will allow the user to change the tension
of the tilting feature. Turn knob (2) clockwise to increase tension
and counter-clockwise to decrease or ease the tension.
To lock return chair to the upright position and push lever (1) in.
To unlock pull lever (1) out.
NOTE: Be careful not to loosen back tilt adjustment knob completely.

• HEIGHT ADJUSTABLE ARMS

Push button (3) in to allow arms to move up or down freely,
release button (3) once the desired heigh is reached.
2

WARNING

1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and knobs are
securely tightened.
3. Check that all bolts screws and knobs are tight every three
months or as needed.
4. Do not overturn back tilt knob when decreasing tension.
5. Dispose of packing material properly. Do not use plastic cover
525-3G3N11
as head covering. It may cause suffocation.
6. Do not use chair as a stepladder.
7. Use this chair for its intended purpose only.
8. Use mild detergent only for cleaning.
