CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTION
Leg frame
A
Title frame
B
Back frame
C
Front frame
D
E
Bottom frame
Seat Frame
H1
Wooden pegs
H2
Screw
H3
H4
Screw
H5
Hook
H6
Circle hook
Strut
H7
Screw
H8
Allen key
H9
QUANTITY
2X
1X
1X
1X
1X
1X
14X
M10X35
10X
M7X90
9X
M4X15
1X
1X
1X
5X
M4X15
2X
5 mm
Model# PAT7017
Product Dimensions:50" W x 24" D x 35" H
H3
Page 01 of 03
