CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when it is not in use.
Dust regularly with small brush or vacuum. Spills should be taken
care of immediately before they harden or stain with a slightly
dampened sponge.
NOTICE
Please make sure that you have all parts indicated before you
begin assembly of this item.
Part List and Hardware List
PIECE
DESCRIPTION
A
Back
B
Seat
C
Side
D
Right Leg
Left Leg
E
Joint bar
F
G1
Allen bolt L
G2
Allen bolt S
G3
Allen screw
G4
Allen bolt S
G5
Allen bolt S
G6
Wrench
G7
Allen Key
QUANTITY
1x
1x
2x
2x
2x
2x
3x
M6x80
3x
M6x50
4x
M6x50
8x
M6x50
4x
M6x30
1x
1x
MODEL# PAT6745
Product Dimension: 82.68"W x 29.13"D x 28.74"H
Weight capacity : 425 lbs
Warning : Do not stand on the bench
Warning : Do not torque bolts / screws
Advertisement
Table of Contents
Related Manuals for Safevieh Outdoor PAT6745
Summary of Contents for Safevieh Outdoor PAT6745
- Page 1 Dust regularly with small brush or vacuum. Spills should be taken care of immediately before they harden or stain with a slightly dampened sponge. NOTICE MODEL# PAT6745 Please make sure that you have all parts indicated before you Product Dimension: 82.68”W x 29.13”D x 28.74”H begin assembly of this item.
- Page 2 PREPARATION Before beginning the assembly of the product, make sure all parts are present. Compare the parts with the package contents list and hardware contents list. If any parts are missing or damaged, do not attempt to assemble the product. Tool required for assembly (included): Allen Key and Wrench.
- Page 3 Step 4: Lift up the side (C) as shown the picture and put down to lock the Step 3: attach the back (A) to the seat (B) as shown on the picture. side on the seat (B) then can use this lounger same as this bench. Then use the Allen bolt L (G1) and the Allen bolt S (G2) and tighten by the Allen Key (G7) and wrench (G6) as shown on the picture.
