Devon&Devon Premiere Console Assembly Instructions Manual page 14

3)
Tighten two nuts (E) on the
threaded bar and insert two
washers (D) as shown.
Make sure that the threaded bar
goes through the slot on the
metal bracket.
5)
Tighten another nut (E) on
the threaded bar and insert
another washer (D) from the
opposite part of the bracket
than the other two.
Repeat the above operations for both legs.
4)
Insert the Allen screw (C)
with the washer (B) in the hole
left free in the corner of the
ceramic basin.
Tighten the Allen screw using the
Allen wrench without locking it
definitively.
6)
Using the 13 mm wrench
tighten the three bolts on the
threaded bar without locking
them definitively.
