SERVICE MANUAL
COLOR TELEVISION
• This Service Manual is the "Revision Publishing" and replaces "Simple
Manual" (S/M Code No. 09-005-431-9T1).
• This Service Manual does not include "ADJUSTMENT". This item will be
issued in the next Supplement.
TV-F2400
S/M Code No. 09-007-431-9R1
U

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TV-F2400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa TV-F2400

Summary of Contents for Aiwa TV-F2400

  • Page 1 All manuals and user guides at all-guides.com TV-F2400 SERVICE MANUAL COLOR TELEVISION • This Service Manual is the “Revision Publishing” and replaces “Simple Manual” (S/M Code No. 09-005-431-9T1). • This Service Manual does not include “ADJUSTMENT”. This item will be issued in the next Supplement.

  • Page 2: Specifications

    All manuals and user guides at all-guides.com SPECIFICATIONS Tuner System Frequency synthesized tuner TV System NTSC-M Channel Coverage VHF: 2 to 13 UHF: 14 to 69 CATV: 5A, A-1 to A-5, A to W, W+1 to W+84 Program Memory Antenna Input 75 ohms, unbalanced Picture Tube 24 in.
