SELF CONTAINED LED EMERGENCY
Model: SPOT DL LED
Self-contained LED emergency with LED lamp 3*1W and constant current control. Designed to work in Maintained
and non-maintained mode. Equipped with high luminosity white LED 3*1W for stable illumination and a small green
Led to indicate the power presence and battery charging.

Characteristics:

.
-
Supply 230 V 50/60Hz
-
Input current: 56mA
-
Maintained/Non Maintained.
-
Green Led indicating the battery charge
-
Output voltage:9.5VDC with 3*1W LED lamp
-
Output current: limited to 270ma.
-
Output power in emergency mode 3.5 W
-
Battery Ni-mh 6V1.2 Ah
-
Autonomy 1 hour
-
Protection against Overloading and end of Battery Discharge
-
Open circuit protection 38 V.( LED lamp)
-
Colour Temperature 5000-5500K
-
Grade IP20
-
Class II device
-
Ambient temperature:0-50ºC
-
Verification test via Telemando TM
-
Battery charging 24 hours
-
Max cross section of cable to be connected 1,5mm
-
Max distance to led lamp 2m
-
Recessed mounting.
-
CE marked as per directives 2006/95/CE and 2004/108CE EMC
-
Manufactured in accordance to norms UNE-EN 60598-2-22UNE-EN 61347-2-13
Model
SPOT DL LED-1S
SPOT DL LED-1W
SPOT DL LED-3S
SPOT DL LED-3W
SPOT DL LED SIGN S
SPOT DL LED SIGN W
Wokring:
Power presence: The device charges permanently the battery and the Green led indicating the charging process in
ON. In maintained mode, LED Lamp is permanently ON and in non-maintained mode the LED LAMP remains OFF
and goes ON in emergency.
Power failure: In case of power failure or low voltage, the luminary enters in emergency mode, the green led
indicating the battery charge goes OFF,
En maintained mode: The driver maintains LED lamp ON with battery power.
En non maintained mode: The Driver switches ON the LED lamp with battery power.
The autonomy of the luminary is 1or 3hours depending on the model.
Verification TEST: Verification during power presence is done via TELEMANDO.
By pressing ON (TM) the luminary enters into emergency mode, and comes back to normal mode as the ON button
is released, see diagram next page.

Installation:

- Make a hole of 70 mm diameter in the ceiling to introduce the driver and the battery and recess the luminary once
connected.
- Please refer to the connection diagrams on next page for connection and follow the following steps.
- Switch OFF the power to make the installation.
- Make connections to the connector (N,L), this line should be permanent, as it is charging the battery permanently
and if the line is cut the luminary will enter in emergency mode.
- Make connection to connector (L1) (see Maintained mode connection diagram), It is also possible to connect a
switch in this line to switch ON/OFF the in maintained mode (see connection diagram)
- Connect the 3*1W LED lamp wire to the driver connector (LED LAMP + -) respecting the polarity indicated
(red+/black-)
- Connect the green LED wire to the driver connector (battery charging indicator), respecting the polarity, the
special connector enables the possibility of connection error.
Lighting Technologies TRQ, S. L.
Frame Color
Autonomy
Silver
1 Hour
White
1 Hour
Silver
3 Hours
White
3 Hours
Silver
---
White
---
Battery
6V - 0,8Ah
6V - 0,8Ah
6V - 2,5Ah
6V - 2,5Ah
---
---
F
IP20
