TRQ LYRA Series Manual

SELF CONTAINED EMERGENCY LUMINARY
SERIE LYRA

Characteristics:

Supply 230 V 50/60Hz.
Non Maintained.
Verification TEST by TEST button incorporated or via TELEMANDO.
Stand by and re-start via Telemando.
Yellow Led indicating, the Battery re-charging.
Autonomy more than 1, 2 or 3 hours (depending on the model)
Grade IP65 IK07 or IP42 IK04, (depending on the model)
Connection via 16 or 20 mm cable
Protection against Overloading and end of Battery Discharge
Protection against the connection errors of TELEMANDO CONNECTOR
Class II Luminary, should be installed in a way that no metal piece exposed is in electrical
contact with either in electrical installation or Conductor of protection.

Norms Applied:

CE as per directives 2006/95/EC LVD and 2004/108/EC of EMC
Manufactured according to norms UNE-EN 60598-2-22, UNE 20-392-93 and in complying with
the norms EN-55015 and EN 50082-1 of electromagnetic compatibility.
Adapted to the Instructions of Low tension Electro technical Norm RBT and NBE CPI 96 of
-
the Basic norm of Edification

Models Available:

Mod Mod.
IP65 IP42
L-100E L-100
L-300E L-300
L-400E L-400
L-500E L-500
L-153E L-153
L-302E L-302
SIGN E SIGN
* Awaiting Certification.
Install & connect the luminary to the main supply.
Check that the Yellow Led indicator indicating the Charging process is lit.
The Batteries are supplied Discharged and they need 24 hours to be charged completely, so
the Luminary will not respond to its Autonomy until 24 hours.

Maintenance:

The Batteries should be changed once their duration gets inferior to the assigned.
The Luminaries should be checked at least once a year.( We recommend every 3months)
The Batteries and tubes should be re-cycled or eliminated in an adequate way.
Before doing any maintenance operation, please make sure that the Main supply is switch off
and the Luminary is in STAND BY Position.

Verification TEST:

Verification test is possible with one of the following Accessories.
MANUAL TEST BUTTON: By pressing this Button, the Luminary goes on Emergency Stage
(Fluorescent Tube ON)
TELEMANDO TM: By pressing the button Test ON, the Luminary starts working on Emergency
in the presence of supply.

Stand by position:

Connect the TELEMANDO TM as indicate din the Diagram of connection
En Emergency stage it is possible to Switch OFFF the Luminary to save the Battery power by
pressing OFF. By pressing ON the Luminary starts working again.
Lighting Technologies TRQ, S. L.
.
Emergency Lamp
E
T5 8W (G5)
T5 8W (G5)
PL-11W (2G7)
PL-11W (2G7)
T5 8W (G5)
T5 8W (G5)
T5 8W (G5)
Battery
Autonomy
Ni-Cd
2.4V 1.5Ah 1 Hour
6V 1.5Ah 1 Hour
6V 1.5Ah 1 Hour
3.6V 4Ah 1 Hour
3.6V 4Ah 3 Hours
3.6V 4Ah 2 Hours
-
.
IP65 IP42
φ Lumen
output
Lumen
100*
260*
352*
500*
141*
250*
- 330*
F
